Today's Message Index:
----------------------
1. 02:10 AM - Re: Flying the Tallapoosa (Pat Ladd)
2. 03:38 AM - Re: Re: Kolb/Jabiru carb overflow (Richard Girard)
3. 04:22 AM - Re: Flying the Tallapoosa (John Bickham)
4. 04:37 AM - Re: Re: Kolb/Jabiru carb overflow (zeprep251@aol.com)
5. 05:57 AM - Re: Kolb/Jabiru carb overflow (Thom Riddle)
6. 06:35 AM - Re: Flying the Tallapoosa (John Hauck)
7. 06:35 AM - Re: Re: Kolb/Jabiru carb overflow (John Hauck)
8. 07:17 AM - Re: Re: Kolb/Jabiru carb overflow (b young)
9. 03:22 PM - Birds of a Feather (Dennis Thate)
Message 1
| INDEX | Back to Main INDEX |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Flying the Tallapoosa |
Nice to see you in the air again, John.
Looks as though you have some good weather as well.
Pat
Message 2
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Kolb/Jabiru carb overflow |
Chris, An old Lycosaurus trick is to put a slit in the breather tube so that
if there is any obstruction in the end of the tube the pressure will push
the slit open and allow the engine to vent.
Rick Girard
On Mon, Jan 17, 2011 at 9:28 PM, ces308 <ces308@ldaco.com> wrote:
>
> Gary and Thom....
>
> I think you hit the nail on the head with crank case pressure....I thought
> it was ok,then I got thinking last night ( I work nights so I had 12 hrs to
> think about it ) and I got looking at the videos I made and the dates I made
> them,then went to the weather channel and matched up outside temps for the
> days it flew and the days it quit and the days it ran good the temps were
> 32+ and the days it quit temps were 10 - 18 *.With a closer look today I
> believe the vent tube was freezing up blocking off the venting of the
> case,The original catch cup I had was loose fitting and starting to come
> apart so this summer I made a new one with fittings in the top and a screw
> on cap for security and it worked great in warmer temps ,but maybe not so
> good in the winter months.I will try to run it tomorrow and will let you
> know how it goes...It all makes sense now and why after everything we did it
> all came back to the same thing !
>
> Thanks Thom and Gary ! I would not have considered this Knowing how simple
> the system is...from now on I check this first, fuel pressure will now be
> monitored all the time now.... and I should have known this too!
> I will let you know for sure tomorrow!
>
> ps...this is the picture of the catch can...i removed the Brillo pad that
> was getting deteriorated and replaced it with paper toweling to soak up any
> moisture and oil...I am back using A Brillo coarse mesh pad again and I
> think I'm going to use larger diameter tubing too..when I took it apart you
> could see where the toweling was right up against the in-coming and out
> going openings...
>
> chris ambrose
> M3X/Jabiru
> N327CS
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=327369#327369
>
>
> Attachments:
>
> http://forums.matronics.com//files/img_1291_214.jpg
>
>
--
Zulu Delta
Kolb Mk IIIC
582 Gray head
4.00 C gearbox
3 blade WD
Thanks, Homer GBYM
It is not bigotry to be certain we are right; but it is bigotry to be unable
to imagine how we might possibly have gone wrong.
- G.K. Chesterton
Message 3
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Flying the Tallapoosa |
Man,
Too bad we can't scrub the weight off our little tummy's!!! Good to see you ya
with the Kolb grin again.
You oughta come visit when it warms a bit.
--------
Thanks too much,
John Bickham
Mark III-C w/ 912UL
St. Francisville, LA
I know many pilots and a few true aviators. There is a distinct difference that
I have the greatest respect for.
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=327401#327401
Message 4
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Kolb/Jabiru carb overflow |
John,
The oil fill tube,dip stick guide,crankcase vent are one and the same.About
3/4 in ID with the base of the tube not far enough above the oil level.The
later model engines have a deeper oil pan,but it really should have a wind
age tray like we used in VWs .I have built a separator mounted on top of th
e engine with 5 vanes in it that cause the vent gases to make sharp turns w
hen leaving the case that SEEMS to help,and have used a PCV valve to try to
hold a negative pressure in the case, but the venting system needs a redes
ign IMHO.If I still have it at the 2000hr TBO,I would try to modify it.It i
s such a sweet engine in other respects.
G.Aman MK-3C Jabiru 2200a 600hrs
PS welcome back!
!
-----Original Message-----
From: John Hauck <jhauck@elmore.rr.com>
Sent: Mon, Jan 17, 2011 10:51 pm
Subject: Re: Kolb-List: Re: Kolb/Jabiru carb overflow
ps...this is the picture of the catch can
chris ambrose
M3X/Jabiru
Chris A/Gang:
Is it mandatory to use a large catch can? or can you configure the breathe
r
hose to dump overboard?
Does the engine blow that much oil through the breather? or is the catch
can also the air/oil seperator?
john h
mkIII
titus, alabama
Message 5
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Kolb/Jabiru carb overflow |
Chris,
Glad you found the culprit!
My rather small air/oil separator has one inlet and two outlets. The top outlet
goes via flex hose directly overboard. The bottom outlet goes to a petcock and
from there it also goes overboard. After every flight, I drain the several drops
of the muck that collects in the bottom using the petcock. As long as I never
let the separator fill up (drain after every flight), no oil or muck comes
out of the upper outlet and the tail stays nice and clean.
I add no more than a 1/2 pint or so of oil between 50 hour changes, so most of
what comes out of the separator is oily water.
--------
Thom Riddle
Buffalo, NY (9G0)
Kolb Slingshot SS-021
Jabiru 2200A #1574
Tennessee Prop 64x32
Don't accept your dog's admiration as conclusive evidence that you are wonderful.
Ann Landers
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=327409#327409
Message 6
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Flying the Tallapoosa |
Nice to see you in the air again, John.
Looks as though you have some good weather as well.
Pat
Thanks, Patrick:
Good to be back up again. Now I have to learn how to fly.
john h
mkIII
Titus, Alabama
Message 7
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Kolb/Jabiru carb overflow |
If I still have it at the 2000hr TBO,I would try to modify it.It is such a
sweet engine in other respects.
G.Aman MK-3C Jabiru 2200a 600hrs
PS welcome back!
!
Gary A/Gang:
Thanks for that info. I have a better understanding of what the Jabiru
folks problem is now.
Is the Jabiru Factory doing anything to help with this problem?
Hopefully, you all can come up with a good solution.
john h
mkIII
Titus, Alabama
Message 8
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Kolb/Jabiru carb overflow |
ps...this is the picture of the catch can...i removed the Brillo pad
that was getting deteriorated and replaced it with paper toweling to
soak up any moisture and oil...I am back using A Brillo coarse mesh pad
again and I think I'm going to use larger diameter tubing too..when I
took it apart you could see where the toweling was right up against the
in-coming and out going openings...
chris ambrose
M3X/Jabiru
N327CS
>>>>>>>>>>>>>>>
if there was someway that you could put some insulation around the
seperator / tubing, it would keep it warm enough it could not ice over.
just thinking outloud here, i have seen some foam tape that would
keep things a bit warmer. as to paper or corse mesh pad... when
working with pnumataic thermostats and controls,, one of the best
filter housings ive seen used a roll of toilet paper as a filter
element. it worked as a filter dryer. and cheap to replace.
boyd young
mkiii
Message 9
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Birds of a Feather |
Birds of a Feather
--------
Both optimists and pessimists contribute to our society. The optimist invents
the airplane and the pessimist the parachute. ~Gil Stern
Faith is believing what you know ain't so - Mark Twain
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=327484#327484
Attachments:
http://forums.matronics.com//files/aerodynamics_101_843.jpg
