Today's Message Index:
----------------------
1. 01:07 PM - Re: Astro Pneumatics (Kirby, Dennis Civ USAF AFMC AFNWC/EN)
2. 03:45 PM - Re: The winter fly-in experience (ropermike)
3. 04:56 PM - Re: prop for 447 on UltraStar? (Masqqqqqqq@aol.com)
4. 05:46 PM - Re: prop for 447 on UltraStar? (TheWanderingWench)
5. 06:15 PM - Re: prop for 447 on UltraStar? (Dana Hague)
6. 06:15 PM - Re: prop for 447 on UltraStar? (Dana Hague)
7. 06:25 PM - Extended riveter nose (Richard Girard)
8. 06:51 PM - Re: prop for 447 on UltraStar? (TheWanderingWench)
9. 07:54 PM - Re: The winter fly-in experience (Ralph B)
10. 09:16 PM - Re: prop for 447 on UltraStar? (slowaero)
Message 1
INDEX | Back to Main INDEX |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Astro Pneumatics |
<< Positive feedback about various companies is always good to hear. >>
Fellow Kolbers -
I also have a similar story: A few years ago, I needed a new strobe
head for my Kolb, from Kuntzleman Electronics. (my old one got dunked
in salt water and died - remember THAT unpleasant story?!)
Same thing - they simply sent me a new one, free of charge. (Thanks
again, Dick!)
Acts of good will like these are good for business - makes a customer
happy to bring return business to them again.
Dennis Kirby
Mark-3, 912ul
Sandia Park, NM
do not archive
Message 2
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: The winter fly-in experience |
I'd give my left one for a radio that sounds that good!
--------
The next best thing to playing and winning is playing and losing!...Mike Hillger
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=331871#331871
Message 3
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: prop for 447 on UltraStar? |
I have used both a 2 blade Precision Prop, and a 4 blade Ultra Prop. Both
are ground adjustable, but I don't remember the pitch I used.
First thing I had to do was have the B box converted to a 2:1 ratio.
My overall preference is for the 2 blade prop. Because I had to fold
and trailer the machine every time I used it, the 4 blade prop had to be
removed every time, and the 2 blade could stay on. I never tried a 3 blade,
and don't know if the wings can fold over it.
Another thing I noticed was the 4 blade prop took a little longer to
wind up, because of the extra weight. It was also a little noticeable in
maneuvering, giving a gyroscopic lag to changing direction. But not much
really. The four blade was a bit quieter than the 2 blade prop.
I only flew it a couple times with the original Cuyuna before it
coughed up a piston, so can't speak about the climb rate............but it's very
good with the Rotax. I was getting about 800 fpm, until I gained some
weight (me not the machine).
I tried to sell my equipment about a year ago, and I guess I asked
way too much, so it's still all available. Maybe you need an engine mount
for that Rotax?
In a message dated 2/19/2011 8:36:23 P.M. Central Standard Time,
d-m-hague@comcast.net writes:
--> Kolb-List message posted by: Dana Hague <d-m-hague@comcast.net>
My UltraStar currently has the original Cuyuna engine with the 50x30
Culver
prop. I just acquired a 447, which I plan to install. Can anybody tell
me
what is a good prop for this combination? I believe (need to confirm)
that
it's a 2.58 ratio B box. I'm thinking 3 blades due to the limited
diameter
possible on the US, can't go 4 blades and fold the wings... perhaps even
smaller than 50" to give better ground clearance?
A friend gave me the engine in the interest of me being quieter than I am
with the 447; a number of people have commented on how loud my plane is.
Also for anybody who's flown the US with both engines, how much
performance
increase should I expect? I calculate about 350fpm better climb in
theory.
-Dana
--
Art and technical perfection are not the same thing in cars, and hard-core
car buffs often prefer art. Which is why they own so many tools.
Message 4
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: prop for 447 on UltraStar? |
I have a friend to whom I'm going to loan my 4-blade ultraprop for his Ultr
astar, on which he's putting a 447. Reading this thread, I realize that he
may not want to use it. He has to fold his wings to get in the hangar.
Also, you write that: "the first thing I had to do was have the B box conve
rted to a 2:1 ratio."
I've been using the prop with a 2:58 ratio B gear box on a 503. Is this jus
t too much for a 447? Is that why you had to reduce the ratio?
Arty Trost
Sandy, Oregon
www.LessonsFromTheEdge.com/uladventure2009.htm
=0A
=0A"Life's a daring adventure or nothing"
=0A Helen Keller
=0A
=0A"I refuse to tip toe through life just to arrive safely at death."
--- On Tue, 2/22/11, Masqqqqqqq@aol.com <Masqqqqqqq@aol.com> wrote:
From: Masqqqqqqq@aol.com <Masqqqqqqq@aol.com>
Subject: Re: Kolb-List: prop for 447 on UltraStar?
=0A=0A =0A=0AI have used both a 2 blade Precision Prop, and a 4 =0Ablade Ul
tra Prop.- Both are ground adjustable, but I don't remember the =0Apitch
I used.=0A--- First thing I had to do was have =0Athe B box converted
to a 2:1 ratio.=0A---- My overall preference is for =0Athe 2 blade
prop.- Because I had to fold and trailer the machine every time =0AI use
d it, the 4 blade prop had to be removed every time, and the 2 blade could
=0Astay on.- I never tried a 3 blade, and don't know if the wings can fol
d =0Aover it.=0A-- Another thing I noticed was the 4 blade =0Aprop took
a little longer to wind up, because of the extra weight.- It was =0Aalso
a little noticeable in maneuvering, giving a gyroscopic lag to changing
=0Adirection.- But not much really.- The four blade was a bit quieter
=0Athan the 2 blade prop.=0A-- I only flew it a couple times with the
=0Aoriginal Cuyuna before it coughed up a piston, so can't speak about the
climb =0Arate............but it's very good with the Rotax.- I was gettin
g about =0A800- fpm, until I gained some weight (me not the =0Amachine).
=0A---- I tried to sell-my =0Aequipment about a year ago, and I g
uess I asked way too much, so it's still all =0Aavailable.- Maybe you nee
d an engine mount for that =0ARotax?=0A--In a message dated 2/19/2011 8
:36:23 P.M. =0ACentral Standard Time, d-m-hague@comcast.net writes:=0A=0A--
> =0A Kolb-List message posted by: Dana Hague =0A <d-m-hague@comcast.net>
My UltraStar currently has the original =0A Cuyuna engine with the 50x30 C
ulver
prop.- I just acquired a 447, =0A which I plan to install.- Can anybod
y tell me
what is a good prop for =0A this combination?- I believe (need to confir
m) that
it's a 2.58 ratio =0A B box.- I'm thinking 3 blades due to the limited d
iameter
possible on =0A the US, can't go 4 blades and fold the wings... perhaps ev
en
smaller than =0A 50" to give better ground clearance?
A friend gave me the engine in the =0A interest of me being quieter than I
am
with the 447; a number of people =0A have commented on how loud my plane i
s.
Also for anybody who's flown =0A the US with both engines, how much perfor
mance
increase should I =0A expect?- I calculate about 350fpm better climb in
=0A theory.
-Dana
--
Art and technical perfection are not the same =0A thing in cars, and hard-
core
car buffs often prefer art.- Which is =0A why they own so many =0Ae =0Ai
es =0Aay =0A - - - - - -- - MATRONICS WEB FORUMS =0A -
- - - -- - List Contribution Web Site =0Ap; - =0A - - -
- - - - - - - - =0A
=0A
Message 5
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: prop for 447 on UltraStar? |
At 08:44 PM 2/22/2011, TheWanderingWench wrote:
>I have a friend to whom I'm going to loan my 4-blade ultraprop for his
>Ultrastar, on which he's putting a 447. Reading this thread, I realize
>that he may not want to use it. He has to fold his wings to get in the hangar.
>
>Also, you write that: "the first thing I had to do was have the B box
>converted to a 2:1 ratio."
>I've been using the prop with a 2:58 ratio B gear box on a 503. Is this
>just too much for a 447? Is that why you had to reduce the ratio?
Arty, what diameter is your Ultraprop? The US is limited to 50", which
isn't all that big. If your 503 was turning it with a 2.58 box it would
probably be too much for a 447.
I would think a 4 blade prop on a 447 would have to set to a really flat
pitch to spin up to speed with a 2:1 box; GSC and WD recommend a 2 blade
prop for that ratio.
How did the Ultraprop work for you? I don't hear real good things about
them... since you have it to loan to your friend I assume you replaced it
with something else?
-Dana
--
"You sure it's broken? Let me make sure..."
Message 6
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: prop for 447 on UltraStar? |
At 07:47 PM 2/22/2011, Masqqqqqqq@aol.com wrote:
>I have used both a 2 blade Precision Prop, and a 4 blade Ultra Prop. Both
>are ground adjustable, but I don't remember the pitch I used.
> First thing I had to do was have the B box converted to a 2:1 ratio.
That's what I though I needed to do, but both the GSC and WD people say
their 3 blade is OK with the 2.58, though I'd need a 2 blade if I regeared
the box to 2:1..
> My overall preference is for the 2 blade prop. Because I had to
> fold and trailer the machine every time I used it, the 4 blade prop had
> to be removed every time, and the 2 blade could stay on. I never tried a
> 3 blade, and don't know if the wings can fold over it.
The wings will clear a 3 but not a 4, so the 4 is out. Were both of yours
50" diameter?
> I only flew it a couple times with the original Cuyuna before it
> coughed up a piston, so can't speak about the climb rate............but
> it's very good with the Rotax. I was getting about 800 fpm, until I
> gained some weight (me not the machine).
That's good to hear... I think mine is around 500 with the Cuyuna.
> I tried to sell my equipment about a year ago, and I guess I asked
> way too much, so it's still all available. Maybe you need an engine
> mount for that Rotax?
Maybe... what does the Rotax mount look like? I was thinking of an adapter
plate for the Cuyuna mount, but that will put the prop lower than the
original, so less ground clearance. Were you trying to sell the whole
plane or just bits and pieces?
-Dana
--
"You sure it's broken? Let me make sure..."
Message 7
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Extended riveter nose |
Three problems with the horizontal stabilizer brackets on the Mk IIIX I'm
working on.
The first was that the brackets were mounted a bit more than 3/8" off to
each other (about a degree of incidence).
Second it is a Mk IIIC to X conversion and when the wider X brackets were
mounted further toward the center of the boom tube it spread the front of
the stabilizers such that the hinges were binding so much that you could
feel them pop over center. Surely not a way to prolong the life of the
elevator hinges.
Third, the builder drilled the mounting holes so close to the flanges of the
bracket it was impossible to get the rivet square with the bracket even
after I solved problem 2 by cutting down the flanges of the brackets and
moving the top hole inboard 3/8".
First I made an extended nose for my air riveter. I won't bore you with the
details, but it could just as easily be done with a piece of 3/8" X .125
tubing (yes, Spruce has that size) 3/4" of an inch long and holding it in
place, or getting an extra nose piece and use some JB Weld to stick it on. I
elected to do it the hard way, although I did cheat and use a loose 3/8-26
thread to approximate a 10mm X 1.0 (.393-25.4 in inches)
Then I had to make a hybrid rivet to accommodate the longer nose. McMaster
Carr carries 3/16" stainless steel rivets in grip lengths out to 1.00 inch.
At 75 cents each by the time you pay shipping this trick gets expensive real
quick, but I only needed 14 and they come in boxes of 10 so it was
tolerable. As you can see from the picture I took the mandrel from a 1.00"
grip rivet and put it in a 1/8-1/4" grip rivet. By the time it was all said
and done each hybrid rivet cost about $1.10 but it worked, the rivets are
tight and all three problems are solved.
Rick Girard
--
Zulu Delta
Mk IIIC
Thanks, Homer GBYM
It isn't necessary to have relatives in Kansas City in order to be unhappy.
- Groucho Marx
Message 8
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: prop for 447 on UltraStar? |
I've gotten lots of flak for using an Ultraprop - folks are constantly tell
ing me that it is very inefficient and a poor choice. Since I've never flow
n my Drifter with another prop, I have no comparison as to efficiency facto
rs. I stuck with the Ultraprop because of its extreme hardiness, which I've
never seen matched in another prop. I've had small screws go through it, a
nd it just kept flying. When it gets dinged, the cracks never travel. It's
very easy to repair in the field. And since I do a lot of rough field out-i
n-the-middle-of-nowhere landings, that's extremely important to me.
I'm not giving up on the ultraprop; I've just put my Drifter in storage for
a while, since I bought a Talon. Since I won't be using the Drifter, I fig
ured I could loan the Ultraprop to a friend. But I'll have to measure it, s
ince it very well may be longer than the 50" limit you said an Ultrastar ca
n take.
Arty Trost
Sandy, Oregon
www.LessonsFromTheEdge.com/uladventure2009.htm
=0A
=0A"Life's a daring adventure or nothing"
=0A Helen Keller
=0A
=0A"I refuse to tip toe through life just to arrive safely at death."
--- On Tue, 2/22/11, Dana Hague <d-m-hague@comcast.net> wrote:
From: Dana Hague <d-m-hague@comcast.net>
Subject: Re: Kolb-List: prop for 447 on UltraStar?
=0AAt 08:44 PM 2/22/2011, TheWanderingWench wrote:
=0AI have a friend to whom I'm going=0Ato loan my 4-blade ultraprop for his
Ultrastar, on which he's putting a=0A447. Reading this thread, I realize t
hat he may not want to use it. He=0Ahas to fold his wings to get in the han
gar.
=0AAlso, you write that: "the first thing I had to do was have the B=0Abox
converted to a 2:1 ratio."
=0AI've been using the prop with a 2:58 ratio B gear box on a 503. Is this
=0Ajust too much for a 447? Is that why you had to reduce the=0Aratio?
=0AArty, what diameter is your Ultraprop?- The US is limited to=0A50", wh
ich isn't all that big.- If your 503 was turning it with=0Aa 2.58 box it
would probably be too much for a 447.
=0AI would think a 4 blade prop on a 447 would have to set to a really flat
=0Apitch to spin up to speed with a 2:1 box; GSC and WD recommend a 2 blade
=0Aprop for that ratio.
=0AHow did the Ultraprop work for you?- I don't hear real good things=0Aa
bout them... since you have it to loan to your friend I assume you=0Areplac
ed it with something else?
=0A-Dana
=0A--=0A"You sure it's broken?- Let me make sure..."=0A=0A=0A=0A
Message 9
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: The winter fly-in experience |
ropermike
> I'd give my left one for a radio that sounds that good!
It's a Microair 760 panel mount radio. I think it sounds better recorded in the
camera because the cabin noise is drastically reduced when it bypasses the headset
sending the audio signal directly to it. My ears hear the cabin noise and
it doesn't sound as clear when listening through the headset, but then my hearing
is getting worse as time passes on. The patch cords are shielded which
helps cutting out engine noise too. I have to say that I was impressed myself
when I played the video back and could hear everything recorded in the cockpit
except a few transmissions that were very noisy like that guy that tried to contact
me when taking off from Gilligans.
Ralph
--------
Ralph B
Original Firestar 447
N91493 E-AB
1000 hours
24 years flying it
Kolbra 912UL
N20386
3 years flying it
150 hrs
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=331908#331908
Message 10
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: prop for 447 on UltraStar? |
I this one had a three blade IVO.
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=331914#331914
Attachments:
http://forums.matronics.com//files/copy_of_daves_thumb2_167.jpg
Other Matronics Email List Services
These Email List Services are sponsored solely by Matronics and through the generous Contributions of its members.
-- Please support this service by making your Contribution today! --
|
