Message 1
INDEX | Back to Main INDEX |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Firestar/HKS First Flight |
Finally after two years of screwing around and getting the HKS engine systems installed
and working, today was initial flight test day.
I did two early morning high speed taxi runs down the runway, then five "crow hops"
from 5 feet to 50 feet AGL down the runway. Early morning before the tower
opened (none of the radio equipment I tried to use would work) , then later
in the evening (after the tower closed at 8PM local) one 10 minute flight doing
ovals around the runway at 500 AGL.
Elevator and rudder light on the controls, ailerons heavy. This will need to be
addressed one way or another.
Required 2 or 3 pounds of forward pressure on the stick for level flight.
Indicated airspeed 50-55 MPH, no idea if this is accurate or not.
Takeoff very short, did not attempt minimum speed landings yet.
Ground steering sensitive but effective.
"Deck Angle" in flight was much different than I had imagined. In order to maintain
level flight the instrument panel was way way down low below the horizon.
Lots lower than where I thought it should be. That is just my inexperience with
the Kolb and UL style aircraft in general.
HKS engine ran well once warmed up. No sagging or "wandering" in flight.
Maximum RPM in flight was 5750, I retarded the throttle to keep it below max continuous
RPM (5800). Might be adding one degree of pitch to the prop blades.
My biggest mistake was due to inexperience with this type of aircraft.... when
I was at 500 AGL it looked to me like I was at 1500 AGL. I thought the altimeter
was wrong, but my ground crew and friends said "yep, looked like you were at
about 500 feet." I was shocked, I thought I was much higher than that!
Bill Berle
www.ezflaphandle.com - safety & performance upgrade for light aircraft
www.grantstar.net - winning proposals for non-profit and for-profit entities
--------------------------------------------
On Sat, 8/4/18, Charlie England <ceengland7@gmail.com> wrote:
Subject: Re: Kolb-List: Re: Firestar/HKS Engine Test Run
To: kolb-list@matronics.com
Date: Saturday, August 4, 2018, 2:41 PM
My neighbor, who did
the covering on my Twinstar, used a similar technique, but
it allows rotating the wing. We pinched the end of a piece
of water pipe (~1 foot long) so it would slide over that
attach point, and bolted it. It obviously has a bit of slop
in the fit, but won't come off. The pipe rests in a
'saddle' made with 2 long 2x4s with a shorter one
between. Height of the center one enough to swing the
leading edge without hitting the floor. Wing tip on a padded
saw horse (or table, etc, whatever works for you). Obviously
requires a helper to move the saw horse while you rotate the
wing. When you're ready to rib stitch with a helper,
something lower like a milk crate would be needed.
Something I wish I'd done while it was
uncovered is to clip the wing back to the end of the main
spar. If the wing is clipped, you can just insert something
in the open end of the spar to support the tip. The end
could be closed with a plate after covering. I may yet clip
it. One side of my hangar has a 30' opening, and I could
keep it on that side instead of the main hangar.
Charlie
On Sat, Aug 4, 2018 at
3:37 PM, Richard Pike <thegreybaron@charter.net>
wrote:
"Richard Pike" <thegreybaron@charter.net>
Sorry I don't have what you are asking for, but here is
the crude way that I did the MKIII: I have a steel support
pole in the middle of the garage that supports the upstairs
floor, and I put a extra long bolt through the rear spar
pivot point, band clamped it to that pole, and then set the
leading edge on two milk crates. One crate near the root and
one near the tip. Worked OK. Not great, but OK.
Had to put it on sawhorses to do the leading edge top and
bottom.
--------
Richard Pike
Kolb MKIII N420P (420ldPoops)
Kingsport, TN 3TN0
Message 2
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Firestar/HKS First Flight |
Congratulations!
--------
Richard Pike
Kolb MKIII N420P (420ldPoops)
Kingsport, TN 3TN0
Forgiving is tough, being forgiven is wonderful, and God's grace really is amazing.
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=482067#482067
Message 3
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Firestar/HKS First Flight |
Congratulations, Bill. Enjoy the view. Sounds like it flew pretty well to me. Heavy
ailerons arent unusual on Kolbs. Id go out and concentrate on learning to
fly your new toy instead of changing things.
George H.
Firestar, FS100,2702 Hirth
14GDH
Mesick, Michigan
gdhelton@gmail.com
Sent from my iPhone
> On Aug 5, 2018, at 3:12 AM, Bill Berle <victorbravo@sbcglobal.net> wrote:
>
>
> Finally after two years of screwing around and getting the HKS engine systems
installed and working, today was initial flight test day.
>
> I did two early morning high speed taxi runs down the runway, then five "crow
hops" from 5 feet to 50 feet AGL down the runway. Early morning before the tower
opened (none of the radio equipment I tried to use would work) , then later
in the evening (after the tower closed at 8PM local) one 10 minute flight doing
ovals around the runway at 500 AGL.
>
> Elevator and rudder light on the controls, ailerons heavy. This will need to
be addressed one way or another.
>
> Required 2 or 3 pounds of forward pressure on the stick for level flight.
>
> Indicated airspeed 50-55 MPH, no idea if this is accurate or not.
>
> Takeoff very short, did not attempt minimum speed landings yet.
>
> Ground steering sensitive but effective.
>
> "Deck Angle" in flight was much different than I had imagined. In order to maintain
level flight the instrument panel was way way down low below the horizon.
Lots lower than where I thought it should be. That is just my inexperience
with the Kolb and UL style aircraft in general.
>
> HKS engine ran well once warmed up. No sagging or "wandering" in flight.
>
> Maximum RPM in flight was 5750, I retarded the throttle to keep it below max
continuous RPM (5800). Might be adding one degree of pitch to the prop blades.
>
> My biggest mistake was due to inexperience with this type of aircraft.... when
I was at 500 AGL it looked to me like I was at 1500 AGL. I thought the altimeter
was wrong, but my ground crew and friends said "yep, looked like you were
at about 500 feet." I was shocked, I thought I was much higher than that!
>
> Bill Berle
> www.ezflaphandle.com - safety & performance upgrade for light aircraft
> www.grantstar.net - winning proposals for non-profit and for-profit entities
>
> --------------------------------------------
> On Sat, 8/4/18, Charlie England <ceengland7@gmail.com> wrote:
>
> Subject: Re: Kolb-List: Re: Firestar/HKS Engine Test Run
> To: kolb-list@matronics.com
> Date: Saturday, August 4, 2018, 2:41 PM
>
> My neighbor, who did
> the covering on my Twinstar, used a similar technique, but
> it allows rotating the wing. We pinched the end of a piece
> of water pipe (~1 foot long) so it would slide over that
> attach point, and bolted it. It obviously has a bit of slop
> in the fit, but won't come off. The pipe rests in a
> 'saddle' made with 2 long 2x4s with a shorter one
> between. Height of the center one enough to swing the
> leading edge without hitting the floor. Wing tip on a padded
> saw horse (or table, etc, whatever works for you). Obviously
> requires a helper to move the saw horse while you rotate the
> wing. When you're ready to rib stitch with a helper,
> something lower like a milk crate would be needed.
> Something I wish I'd done while it was
> uncovered is to clip the wing back to the end of the main
> spar. If the wing is clipped, you can just insert something
> in the open end of the spar to support the tip. The end
> could be closed with a plate after covering. I may yet clip
> it. One side of my hangar has a 30' opening, and I could
> keep it on that side instead of the main hangar.
> Charlie
>
>
> On Sat, Aug 4, 2018 at
> 3:37 PM, Richard Pike <thegreybaron@charter.net>
> wrote:
> "Richard Pike" <thegreybaron@charter.net>
>
>
>
> Sorry I don't have what you are asking for, but here is
> the crude way that I did the MKIII: I have a steel support
> pole in the middle of the garage that supports the upstairs
> floor, and I put a extra long bolt through the rear spar
> pivot point, band clamped it to that pole, and then set the
> leading edge on two milk crates. One crate near the root and
> one near the tip. Worked OK. Not great, but OK.
>
>
>
> Had to put it on sawhorses to do the leading edge top and
> bottom.
>
>
>
> --------
>
> Richard Pike
>
> Kolb MKIII N420P (420ldPoops)
>
> Kingsport, TN 3TN0
>
>
>
>
>
>
>
>
Message 4
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Firestar/HKS First Flight |
Billy Berle/Kolbers:
I guess it's safe for me to make a comment this morning. I've have a couple cups
of coffee.
Reread what my friend George H wrote below. Best advice you will get this morning,
in my humble opinion.
Ailerons on Kolbs are heavy because you have a lot of aileron for that big wing.
That's the way Homer Kolb wanted it. His idea of flying a Kolb was low and
slow, right down in the tree tops, with plenty of aileron authority right through
the stall. Kolbs are not Pitts or F-16s. Don't expect them to be. 34 years
ago I was concerned about the heavy ailerons on my Ultrastar, then my Firestar,
and my MKIII. Coming out of helicopters it seemed to take a ton of strength
to fly it like I would a helicopter. Homer Kolb always told me to be gentle
and the Kolb will do what you want it to. It is not a yank and bank airplane.
I don't know of any old experienced aviator that flies "yank and bank".
Most all are very smooth, gentle pilots, especially on the ground. Slow down...the
ailerons will get lighter. Increase speed and increase aileron resistance.
Unless you changed something in the aileron controls, they should be ok.
Some of the older Firestar II's had some problems with the Homer designed universal
joint on the aileron torque tube. Brother Jim Hauck, while working and
helping New Kolb Aircraft get organized in London, KY, in 1998, solved that
problem by convincing Kolb to change to a sealed aircraft universal joint. Much
more expensive, but a much better system.
I got the same sensation when I first flew my Kolb. Felt like I was going to tip
over forward. Takes a very short time to get used to level flight attitude.
It may be different from "real" airplanes.
Over many years I have discovered that a prop, boat and airplane, should be pitched
to achieve the rpm red line when flying wide open throttle, straight and
level flight. That will give you the best climb and cruise performance with a
in flight fixed pitch prop. You probably weren't flying WOT when you were turning
5750, but that seems like a good place to stay until you learn how to fly
the Kolb. You can repitch later on down the road when you get some experience
flying the bird.
Different perception in altitude, now you are experiencing what real flying is
all about. Nothing like flying a Kolb.
Good luck and be safe,
john h
mkIII
Titus, Alabama
Congratulations, Bill. Enjoy the view. Sounds like it flew pretty well to me. Heavy
ailerons arent unusual on Kolbs. Id go out and concentrate on learning to
fly your new toy instead of changing things.
George H.
Firestar, FS100,2702 Hirth
14GDH
Mesick, Michigan
gdhelton@gmail.com
Message 5
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
I've found a hammer to be as useful as any other tool in my tool box!
Arty
"I refuse to tip toe through life just to arrive safely at death."=C2- To
ny Campolo
On Thursday, August 2, 2018, 10:53:17 AM PDT, west1m <west1m@hotmail.co
m> wrote:
We went out for flight the other day, flew for about three hours. Great wea
ther for the flight . After cruising over a few private airstrips, sand and
rock pits and a bunch of field sprinklers around New Richmond we refueled
and flew to Cumberland. There we bought gas and the manager offered us the
courtesy car to go into town and get lunch. When we got back Randy's BeLite
wouldn't start
After the mechanic tried to help us jump it it was clear it was a starter i
ssue. So I borrowed a hammer from him whacked the starter a few times and e
verything worked just fine and we thanked him for the help and flew back to
New Richmond. There was a large float plane there getting engine work. I t
hink this ia the kind of plane we took to Catalina Island (california) when
I was a kid.
http://www.west1m.com/July_30_2018/index.html
--------
West1m
Hastings, MN
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=482019#482019
Attachments:
http://forums.matronics.com//files/floatplane_776.jpg
http://forums.matronics.com//files/basslake2_184.jpg
http://forums.matronics.com//files/basslake1_135.jpg
S -
WIKI -
-
=C2- =C2- =C2- =C2- =C2- -Matt Dralle, List Admin.
Message 6
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Firestar/HKS First Flight |
A few of us have addressed the heavy aileron condition by redrilling the attach
point connection of the control rods inboard 1 on the control tube angle flange.
Not much change in effectiveness but noticeable change in required effort.
Did this on the FS2 and MK3C as well.
Sent from my iPhone
> On Aug 5, 2018, at 7:54 AM, George Helton <gdhelton@gmail.com> wrote:
>
>
> Congratulations, Bill. Enjoy the view. Sounds like it flew pretty well to me.
Heavy ailerons arent unusual on Kolbs. Id go out and concentrate on learning
to fly your new toy instead of changing things.
> George H.
> Firestar, FS100,2702 Hirth
> 14GDH
> Mesick, Michigan
> gdhelton@gmail.com
>
> Sent from my iPhone
>
>> On Aug 5, 2018, at 3:12 AM, Bill Berle <victorbravo@sbcglobal.net> wrote:
>>
>>
>> Finally after two years of screwing around and getting the HKS engine systems
installed and working, today was initial flight test day.
>>
>> I did two early morning high speed taxi runs down the runway, then five "crow
hops" from 5 feet to 50 feet AGL down the runway. Early morning before the tower
opened (none of the radio equipment I tried to use would work) , then later
in the evening (after the tower closed at 8PM local) one 10 minute flight doing
ovals around the runway at 500 AGL.
>>
>> Elevator and rudder light on the controls, ailerons heavy. This will need to
be addressed one way or another.
>>
>> Required 2 or 3 pounds of forward pressure on the stick for level flight.
>>
>> Indicated airspeed 50-55 MPH, no idea if this is accurate or not.
>>
>> Takeoff very short, did not attempt minimum speed landings yet.
>>
>> Ground steering sensitive but effective.
>>
>> "Deck Angle" in flight was much different than I had imagined. In order to maintain
level flight the instrument panel was way way down low below the horizon.
Lots lower than where I thought it should be. That is just my inexperience
with the Kolb and UL style aircraft in general.
>>
>> HKS engine ran well once warmed up. No sagging or "wandering" in flight.
>>
>> Maximum RPM in flight was 5750, I retarded the throttle to keep it below max
continuous RPM (5800). Might be adding one degree of pitch to the prop blades.
>>
>> My biggest mistake was due to inexperience with this type of aircraft.... when
I was at 500 AGL it looked to me like I was at 1500 AGL. I thought the altimeter
was wrong, but my ground crew and friends said "yep, looked like you were
at about 500 feet." I was shocked, I thought I was much higher than that!
>>
>> Bill Berle
>> www.ezflaphandle.com - safety & performance upgrade for light aircraft
>> www.grantstar.net - winning proposals for non-profit and for-profit entities
>>
>> --------------------------------------------
>> On Sat, 8/4/18, Charlie England <ceengland7@gmail.com> wrote:
>>
>> Subject: Re: Kolb-List: Re: Firestar/HKS Engine Test Run
>> To: kolb-list@matronics.com
>> Date: Saturday, August 4, 2018, 2:41 PM
>>
>> My neighbor, who did
>> the covering on my Twinstar, used a similar technique, but
>> it allows rotating the wing. We pinched the end of a piece
>> of water pipe (~1 foot long) so it would slide over that
>> attach point, and bolted it. It obviously has a bit of slop
>> in the fit, but won't come off. The pipe rests in a
>> 'saddle' made with 2 long 2x4s with a shorter one
>> between. Height of the center one enough to swing the
>> leading edge without hitting the floor. Wing tip on a padded
>> saw horse (or table, etc, whatever works for you). Obviously
>> requires a helper to move the saw horse while you rotate the
>> wing. When you're ready to rib stitch with a helper,
>> something lower like a milk crate would be needed.
>> Something I wish I'd done while it was
>> uncovered is to clip the wing back to the end of the main
>> spar. If the wing is clipped, you can just insert something
>> in the open end of the spar to support the tip. The end
>> could be closed with a plate after covering. I may yet clip
>> it. One side of my hangar has a 30' opening, and I could
>> keep it on that side instead of the main hangar.
>> Charlie
>>
>>
>> On Sat, Aug 4, 2018 at
>> 3:37 PM, Richard Pike <thegreybaron@charter.net>
>> wrote:
>> "Richard Pike" <thegreybaron@charter.net>
>>
>>
>>
>> Sorry I don't have what you are asking for, but here is
>> the crude way that I did the MKIII: I have a steel support
>> pole in the middle of the garage that supports the upstairs
>> floor, and I put a extra long bolt through the rear spar
>> pivot point, band clamped it to that pole, and then set the
>> leading edge on two milk crates. One crate near the root and
>> one near the tip. Worked OK. Not great, but OK.
>>
>>
>>
>> Had to put it on sawhorses to do the leading edge top and
>> bottom.
>>
>>
>>
>> --------
>>
>> Richard Pike
>>
>> Kolb MKIII N420P (420ldPoops)
>>
>> Kingsport, TN 3TN0
>>
>>
>>
>>
>>
>>
>>
>>
>
>
>
>
Message 7
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Firestar/HKS First Flight |
My Mark III Xtra also has a nose down position in level flight. It is much different
from the 152's, 172's and J-3's that I've flown. I still occasionally
find myself climbing thinking that I was descending when I was really flying level.
The plus side is that this attitude gives you a fantastic view!
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=482075#482075
Message 8
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Firestar/HKS First Flight |
THANK YOU John H and everyone else for your comments. Please tell me more about
a universal joint in the aileron torque tube?!?!?
Are you referring to the U-joint in the steel tube under the seat on the aircraft
centerline or are you saying there is a U-joint in the aileron tube itself
on the wing?
My ailerons are very easy to move with two fingers when the aircraft is on the
ground, but in flight with air loads on the wings the ailerons are heavy.
My INITIAL assessment of the ROOT CAUSE of the problem is that one or more of these
things is causing it:
1) Large ailerons that simply need more muscle to move in flight (per John H's
comment)
2) Piano hinges are binding because the trailing edge of the wing is not a perfect
straight line any more once the wings are lifting
3) The "aluminum aileron leading edge/tube is being asked to move up and down as
well as twisting, because the hinge axis is not in the center of the tube
I am not loooking for an aerobatic or air combat maneuver airplane, but I am hoping
to have the Kolb aileron control as light and responsive and pleasant as
the Kolb rudder and elevator are.
BTW my giant tall landing gear definitely makes the airplane a little more squirrely
on the ground than a stock Kolb would probably be ! But it is manageable
thus far. Haven't had any crosswind or gusty situations yet, Time will tell if
I bit off more than I can chew with the landing gear :)
Bill Berle
www.ezflaphandle.com - safety & performance upgrade for light aircraft
www.grantstar.net - winning proposals for non-profit and for-profit entities
--------------------------------------------
On Sun, 8/5/18, John Hauck <jhauck@elmore.rr.com> wrote:
Subject: RE: Kolb-List: Firestar/HKS First Flight
To: kolb-list@matronics.com
Date: Sunday, August 5, 2018, 7:31 AM
Hauck" <jhauck@elmore.rr.com>
Billy Berle/Kolbers:
I guess it's safe for me to make a
comment this morning. I've have a couple cups of
coffee.
Reread what my friend George H wrote
below. Best advice you will get this morning, in my
humble opinion.
Ailerons on Kolbs are heavy because you
have a lot of aileron for that big wing. That's the
way Homer Kolb wanted it. His idea of flying a Kolb
was low and slow, right down in the tree tops, with plenty
of aileron authority right through the stall. Kolbs
are not Pitts or F-16s. Don't expect them to be.
34 years ago I was concerned about the heavy ailerons on my
Ultrastar, then my Firestar, and my MKIII. Coming out of
helicopters it seemed to take a ton of strength to fly it
like I would a helicopter. Homer Kolb always told me
to be gentle and the Kolb will do what you want it to.
It is not a yank and bank airplane. I don't know of
any old experienced aviator that flies "yank and
bank". Most all are very smooth, gentle pilots,
especially on the ground. Slow down...the ailerons
will get lighter. Increase speed and increase aileron
resistance. Unless you changed something in the
aileron controls, they should be ok. Some of the older
Firestar II's had some problems!
with the Homer designed
universal joint on the aileron torque tube. Brother
Jim Hauck, while working and helping New Kolb Aircraft get
organized in London, KY, in 1998, solved that problem by
convincing Kolb to change to a sealed aircraft universal
joint. Much more expensive, but a much better system.
I got the same sensation when I first
flew my Kolb. Felt like I was going to tip over
forward. Takes a very short time to get used to level
flight attitude. It may be different from "real"
airplanes.
Over many years I have discovered that
a prop, boat and airplane, should be pitched to achieve the
rpm red line when flying wide open throttle, straight and
level flight. That will give you the best climb and
cruise performance with a in flight fixed pitch prop.
You probably weren't flying WOT when you were turning 5750,
but that seems like a good place to stay until you learn how
to fly the Kolb. You can repitch later on down the
road when you get some experience flying the bird.
Different perception in altitude, now
you are experiencing what real flying is all about.
Nothing like flying a Kolb.
Good luck and be safe,
john h
mkIII
Titus, Alabama
George Helton <gdhelton@gmail.com>
Congratulations, Bill. Enjoy the view.
Sounds like it flew pretty well to me. Heavy ailerons
arent unusual on Kolbs. Id go out and concentrate on
learning to fly your new toy instead of changing things.
George H.
Firestar, FS100,2702 Hirth
14GDH
Mesick, Michigan
gdhelton@gmail.com
The Kolb-List Email Forum -
Navigator to browse
List Un/Subscription,
7-Day Browse, Chat, FAQ,
- MATRONICS WEB FORUMS -
via the Web Forums!
- NEW MATRONICS LIST WIKI -
Email List Wiki!
- List Contribution Web Site -
support!
-Matt Dralle, List Admin.
Message 9
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Firestar/HKS First Flight |
I was curious about how level my Firefly was after reading the comment about looking
down. It looks fairly level in this pic
--------
West1m
Hastings, MN
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=482083#482083
Attachments:
http://forums.matronics.com//files/level_247.jpg
Message 10
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Firestar/HKS First Flight |
Bill, John H. Is absolutely right. The faster you push the wing through the air,
the heavier your ailerons will get. Conversely, the slower you fly the lighter
they become. The hinges are only offset of center to provide you with differential
effect. That cuts down on adverse yaw.
Concentrate on learning to fly your airplane in its present setup. You will find
after a few hours that its quite nice to use a little side stick pressure then
using a bunch of side stick travel.
Your plane sounds like it flying properly. Become more of a flyer and less of an
engineer. Learn to land the thing with that strange gear. Keep your airspeed
up on approach for the first few hours. Like Homer Kolb said so many years ago.
Keep thy airspeed up, lest ye smite the ground.
Have a great day!
George H.
Firestar, FS100, 2702 Hirth
14GDH
Mesick, Michigan
gdhelton@gmail.com
Sent from my iPhone
> On Aug 5, 2018, at 2:17 PM, Bill Berle <victorbravo@sbcglobal.net> wrote:
>
>
> THANK YOU John H and everyone else for your comments. Please tell me more about
a universal joint in the aileron torque tube?!?!?
>
> Are you referring to the U-joint in the steel tube under the seat on the aircraft
centerline or are you saying there is a U-joint in the aileron tube itself
on the wing?
>
> My ailerons are very easy to move with two fingers when the aircraft is on the
ground, but in flight with air loads on the wings the ailerons are heavy.
>
> My INITIAL assessment of the ROOT CAUSE of the problem is that one or more of
these things is causing it:
>
> 1) Large ailerons that simply need more muscle to move in flight (per John H's
comment)
> 2) Piano hinges are binding because the trailing edge of the wing is not a perfect
straight line any more once the wings are lifting
> 3) The "aluminum aileron leading edge/tube is being asked to move up and down
as well as twisting, because the hinge axis is not in the center of the tube
>
> I am not loooking for an aerobatic or air combat maneuver airplane, but I am
hoping to have the Kolb aileron control as light and responsive and pleasant as
the Kolb rudder and elevator are.
>
> BTW my giant tall landing gear definitely makes the airplane a little more squirrely
on the ground than a stock Kolb would probably be ! But it is manageable
thus far. Haven't had any crosswind or gusty situations yet, Time will tell
if I bit off more than I can chew with the landing gear :)
>
>
> Bill Berle
> www.ezflaphandle.com - safety & performance upgrade for light aircraft
> www.grantstar.net - winning proposals for non-profit and for-profit entities
>
> --------------------------------------------
> On Sun, 8/5/18, John Hauck <jhauck@elmore.rr.com> wrote:
>
> Subject: RE: Kolb-List: Firestar/HKS First Flight
> To: kolb-list@matronics.com
> Date: Sunday, August 5, 2018, 7:31 AM
>
> Hauck" <jhauck@elmore.rr.com>
>
> Billy Berle/Kolbers:
>
> I guess it's safe for me to make a
> comment this morning. I've have a couple cups of
> coffee.
>
> Reread what my friend George H wrote
> below. Best advice you will get this morning, in my
> humble opinion.
>
> Ailerons on Kolbs are heavy because you
> have a lot of aileron for that big wing. That's the
> way Homer Kolb wanted it. His idea of flying a Kolb
> was low and slow, right down in the tree tops, with plenty
> of aileron authority right through the stall. Kolbs
> are not Pitts or F-16s. Don't expect them to be.
> 34 years ago I was concerned about the heavy ailerons on my
> Ultrastar, then my Firestar, and my MKIII. Coming out of
> helicopters it seemed to take a ton of strength to fly it
> like I would a helicopter. Homer Kolb always told me
> to be gentle and the Kolb will do what you want it to.
> It is not a yank and bank airplane. I don't know of
> any old experienced aviator that flies "yank and
> bank". Most all are very smooth, gentle pilots,
> especially on the ground. Slow down...the ailerons
> will get lighter. Increase speed and increase aileron
> resistance. Unless you changed something in the
> aileron controls, they should be ok. Some of the older
> Firestar II's had some problems!
> with the Homer designed
> universal joint on the aileron torque tube. Brother
> Jim Hauck, while working and helping New Kolb Aircraft get
> organized in London, KY, in 1998, solved that problem by
> convincing Kolb to change to a sealed aircraft universal
> joint. Much more expensive, but a much better system.
>
> I got the same sensation when I first
> flew my Kolb. Felt like I was going to tip over
> forward. Takes a very short time to get used to level
> flight attitude. It may be different from "real"
> airplanes.
>
> Over many years I have discovered that
> a prop, boat and airplane, should be pitched to achieve the
> rpm red line when flying wide open throttle, straight and
> level flight. That will give you the best climb and
> cruise performance with a in flight fixed pitch prop.
> You probably weren't flying WOT when you were turning 5750,
> but that seems like a good place to stay until you learn how
> to fly the Kolb. You can repitch later on down the
> road when you get some experience flying the bird.
>
> Different perception in altitude, now
> you are experiencing what real flying is all about.
> Nothing like flying a Kolb.
>
> Good luck and be safe,
>
> john h
> mkIII
> Titus, Alabama
>
>
>
>
>
> George Helton <gdhelton@gmail.com>
>
> Congratulations, Bill. Enjoy the view.
> Sounds like it flew pretty well to me. Heavy ailerons
> arent unusual on Kolbs. Id go out and concentrate on
> learning to fly your new toy instead of changing things.
> George H.
> Firestar, FS100,2702 Hirth
> 14GDH
> Mesick, Michigan
> gdhelton@gmail.com
>
>
>
>
> The Kolb-List Email Forum -
> Navigator to browse
> List Un/Subscription,
> 7-Day Browse, Chat, FAQ,
> - MATRONICS WEB FORUMS -
> via the Web Forums!
> - NEW MATRONICS LIST WIKI -
> Email List Wiki!
> - List Contribution Web Site -
> support!
>
> -Matt Dralle, List Admin.
>
>
>
>
>
>
>
>
Message 11
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Firestar/HKS First Flight |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Message 12
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Firestar/HKS First Flight |
Bill,
First, congratulations on your first flight. That is always a milestone
no matter how many times you have done it.
Second, it sounds like your plane is performing just as it should. My
Kolb is a Firefly so my experience is only similar.
Third, the other guys are correct. At this point the only reason to go
making changes is if you have a serious problem like one wing is so
heavy it will barely fly level. Keep flying and getting to know your
bird. As long as it is not showing any dangerous traits leave well
enough alone until you have become intimate with the flight
characteristics over the entire envelope. You can change the mechanical
advantage of the aileron push tubes by moving the bottom ends inward but
don=99t forget you trade travel distance for that advantage. This
may be well and good in calm conditions but believe me when I tell you
that I have found myself needing every bit of length of throw at the
stick end of things on more than one occasion. It was not my intention
to fly in those conditions but they do happen. You sure as heck
don=99t want to run out of aileron travel when you need it most.
This is most noticeable at slower speeds and where are you likely to be
at those slower speeds but on takeoff or approach the most notably
critical portions of flight. When you are up cruising around at the
upper end of the speed envelope and the ailerons seem
=9Cheavy=9D just remember that you don=99t need much
movement to accomplish your desires so the amount of force is not that
great.
The best advice I got when learning to fly the Firefly was to put my
elbow on my leg and fly with my fingers. It worked and proved that it
really does not take that much force to roll the wings. So keep flying
and keep analyzing and keep thinking before you go changing anything.
After all your hard work to get airborne go enjoy it! My bet is you will
start having so much fun when you are not over thinking things you will
actually forget to think about them.
Fourth, Congratulations! Now go do it again!
Best wishes and safe skies,
Stuart
From: owner-kolb-list-server@matronics.com
[mailto:owner-kolb-list-server@matronics.com] On Behalf Of lcottrell1020
Sent: Sunday, August 05, 2018 5:15 PM
Subject: RE: Kolb-List: Firestar/HKS First Flight
The firestar has heavy ailerons. Nothing much you can do, other than
move the control rods closer to the center. I tried it but didn't like
it. I have gotten used to using my knees to assist. It's just part of
having a Kolb. If you go slow enough they are fine. Too fast and they
are stiff. There have been some experiments with spades, but nothing of
definite results. You will either get used to it, or get something else.
Larry
Sent from my Verizon, Samsung Galaxy smartphone
-------- Original message --------
From: Bill Berle <victorbravo@sbcglobal.net>
Subject: RE: Kolb-List: Firestar/HKS First Flight
THANK YOU John H and everyone else for your comments. Please tell me
more about a universal joint in the aileron torque tube?!?!?
Are you referring to the U-joint in the steel tube under the seat on the
aircraft centerline or are you saying there is a U-joint in the aileron
tube itself on the wing?
My ailerons are very easy to move with two fingers when the aircraft is
on the ground, but in flight with air loads on the wings the ailerons
are heavy.
My INITIAL assessment of the ROOT CAUSE of the problem is that one or
more of these things is causing it:
1) Large ailerons that simply need more muscle to move in flight (per
John H's comment)
2) Piano hinges are binding because the trailing edge of the wing is not
a perfect straight line any more once the wings are lifting
3) The "aluminum aileron leading edge/tube is being asked to move up and
down as well as twisting, because the hinge axis is not in the center of
the tube
I am not loooking for an aerobatic or air combat maneuver airplane, but
I am hoping to have the Kolb aileron control as light and responsive and
pleasant as the Kolb rudder and elevator are.
BTW my giant tall landing gear definitely makes the airplane a little
more squirrely on the ground than a stock Kolb would probably be ! But
it is manageable thus far. Haven't had any crosswind or gusty situations
yet, Time will tell if I bit off more than I can chew with the landing
gear :)
Bill Berle
www.ezflaphandle.com - safety & performance upgrade for light aircraft
www.grantstar.net - winning proposals for non-profit and
for-profit entities
--------------------------------------------
On Sun, 8/5/18, John Hauck <jhauck@elmore.rr.com> wrote:
Subject: RE: Kolb-List: Firestar/HKS First Flight
Hauck" <jhauck@elmore.rr.com>
Billy Berle/Kolbers:
I guess it's safe for me to make a
comment this morning. I've have a couple cups of
coffee.
Reread what my friend George H wrote
below. Best advice you will get this morning, in my
humble opinion.
Ailerons on Kolbs are heavy because you
have a lot of aileron for that big wing. That's the
way Homer Kolb wanted it. His idea of flying a Kolb
was low and slow, right down in the tree tops, with plenty
of aileron authority right through the stall. Kolbs
are not Pitts or F-16s. Don't expect them to be.
34 years ago I was concerned about the heavy ailerons on my
Ultrastar, then my Firestar, and my MKIII. Coming out of
helicopters it seemed to take a ton of strength to fly it
like I would a helicopter. Homer Kolb always told me
to be gentle and the Kolb will do what you want it to.
It is not a yank and bank airplane. I don't know of
any old experienced aviator that flies "yank and
bank". Most all are very smooth, gentle pilots,
especially on the ground. Slow down...the ailerons
will get lighter. Increase speed and increase aileron
resistance. Unless you changed something in the
aileron controls, they should be ok. Some of the older
Firestar II's had some problems!
with the Homer designed
universal joint on the aileron torque tube. Brother
Jim Hauck, while working and helping New Kolb Aircraft get
organized in London, KY, in 1998, solved that problem by
convincing Kolb to change to a sealed aircraft universal
joint. Much more expensive, but a much better system.
I got the same sensation when I first
flew my Kolb. Felt like I was going to tip over
forward. Takes a very short time to get used to level
flight attitude. It may be different from "real"
airplanes.
Over many years I have discovered that
a prop, boat and airplane, should be pitched to achieve the
rpm red line when flying wide open throttle, straight and
level flight. That will give you the best climb and
cruise performance with a in flight fixed pitch prop.
You probably weren't flying WOT when you were turning 5750,
but that seems like a good place to stay until you learn how
to fly the Kolb. You can repitch later on down the
road when you get some experience flying the bird.
Different perception in altitude, now
you are experiencing what real flying is all about.
Nothing like flying a Kolb.
Good luck and be safe,
john h
mkIII
Titus, Alabama
George Helton <gdhelton@gmail.com>
Congratulations, Bill. Enjoy the view.
Sounds like it flew pretty well to me. Heavy ailerons
aren=99t unusual on Kolbs. I=99d go out and concentrate on
learning to fly your new toy instead of changing things.
George H.
Firestar, FS100,2702 Hirth
14GDH
Mesick, Michigan
gdhelton@gmail.com
The Kolb-List Email Forum -
Navigator to browse
List Un/Subscription,
7-Day Browse, Chat, FAQ,
- MATRONICS WEB FORUMS -
via the Web Forums!
- NEW MATRONICS LIST WIKI -
Email List Wiki!
- List Contribution Web Site -
support!
-Matt Dralle, List Admin.
Message 13
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Firestar/HKS First Flight |
Plan to fly for many hours with the ailerons just like they are. Heavy ailerons
are perfectly normal for a Kolb. Once you know your airplane inside out, you
might want to try drilling a couple of holes in the aileron bellcrank a bit closer
to the pivot point and moving the bottom ends of the aileron pushrods closer
to the pivot; it will change the leverage arm and the ailerons will become
much lighter.
You will lose some aileron deflection. Possibly some control authority. Some on
this list think that is anathema, others are comfortable with it. Your call.
But after you have 50-75 hours in your airplane, you will be able to decide for
yourself, and if you don't like it; you can put them back like they were.
In the meantime, everything that Stuart, John and Larry - among others - have
said is absolutely correct. Kolbs have heavy ailerons, and they fly just fine
with heavy ailerons. So do Stearmans.
--------
Richard Pike
Kolb MKIII N420P (420ldPoops)
Kingsport, TN 3TN0
Forgiving is tough, being forgiven is wonderful, and God's grace really is amazing.
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=482102#482102
Other Matronics Email List Services
These Email List Services are sponsored solely by Matronics and through the generous Contributions of its members.
-- Please support this service by making your Contribution today! --
|
