Message 1
| INDEX | Back to Main INDEX |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | How hard is it to get into the front seat |
I think I remember seeing a video showing that it was pretty difficult. The reason
I ask is because my misses is not the most flexible person and she has a bad
back. I really wish to build a Pietenpol with a Model A engine, but I also
want to take her flying and show her why there is nothing else like it.
Charley
Message 2
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
Charley,
Keri-Ann Price sells plans for a modification to add a door to the passenger
seat. Her website is:
http://www.geocities.com/keriannprice/Pietenpol_Plan_Packages.html
Greg
----- Original Message -----
From: "charles loomis" <rameses32@yahoo.com>
Sent: Tuesday, August 05, 2008 3:48 AM
Subject: Pietenpol-List: How hard is it to get into the front seat
>
> I think I remember seeing a video showing that it was pretty difficult.
> The reason I ask is because my misses is not the most flexible person and
> she has a bad back. I really wish to build a Pietenpol with a Model A
> engine, but I also want to take her flying and show her why there is
> nothing else like it.
> Charley
>
>
>
Message 3
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Homemade Turnbuckles |
Bill,
Dale Johnson built a pull tester for testing the cables on NX18235. We
also used it to test some homemade turnbuckle barrels.
Dale would be happy to do a test on one or more of your turnbuckles.
Let me know if you are interested.
Greg Cardinal
----- Original Message -----
From: Bill Church
To: pietenpol-list@matronics.com
Sent: Thursday, July 31, 2008 12:34 PM
Subject: RE: Pietenpol-List: Homemade Turnbuckles
Ken,
I kind of got sidetracked away from the homemade turnbuckles for a
while, and I've actually been building my tailfeathers. So, the short
answer to your question is "No, I haven't".
Having said that, here's the long answer.
I didn't do any strength calculations, but I have a strong feeling
that the turnbuckles as I made them will be sufficient in strength, but
I have yet to do some real-world pull testing to see what they can
safely handle. Before I do the pull test I wanted to refine the design a
bit to make them a bit more user friendly. That way I'll be testing the
proper part, not just something similar. I still plan to do it, just not
right now. If you need an answer right now, I think just about anyone
could make up a set of these in a short period of time, and then do
their own testing using a simple apparatus (lever and pivot). When I do
get around to revising the design and doing the pull-testing, I'll share
the results with the list.
If you want more details about how I made the prototype, let me know.
Bill C.
-------------------------------------------------------------------------
-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of KMHeide,
BA, CPO, FAAOP
Sent: Thursday, July 31, 2008 12:37 PM
To: pietenpol-list@matronics.com
Subject: RE: Pietenpol-List: Homemade Turnbuckles
Bill,
Have you nailed down the materials (thickness, width, length,
rod size, etc) to manufacture the turnbuckles for the tail section?
After seeing the price for the turnbuckles on Aircraft Spruce and
others, I think making my own would be a great idea... any assistance?
Kenneth M. Heide, BA, CPO, FAAOP
Message 4
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Ribs and sanding |
Look on the back. Most quality sandpaper will have the grit size printed on the
back. It will be a number ranging from 60 (very coarse) to 600 (extremely fine).
Do you have the Tony Bingelis books? If not, you should buy them.
Jack Phillips
NX899JP
Raleigh, NC
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com [mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Monday, August 04, 2008 11:25 PM
Subject: Re: Pietenpol-List: Re: Ribs and sanding
Sorry Everyone,
Yep that is what I was asking. just dealing with sanding then gluing. I am building
with douglas fir so spruce is of no concern to me. Another question I am
unsure of what grit of sandpaper I am using, and my dad is unsure to. If I can
describe it by its color the sandpaper I am using is a grey color.
take care,
Ben
----- Original Message ----
From: Bill Church <billspiet@sympatico.ca>
Sent: Monday, August 4, 2008 9:30:56 PM
Subject: Pietenpol-List: Re: Ribs and sanding
Not sure if I should step into this one, since it looks like there is some confusion,
but here goes anyway.
I'm going to assume that Ben's question has to do with sanding the bonding surface
of the plywood gussets for his wing ribs. If that's right, then Glenn's reply
is what you're looking for. Just scuff up the surface, since plywood can have
a "glazed" surface as it is received. This glazed surface just needs to be
scratched a bit to permit the epoxy to penetrate the plywood and make a decent
bond. You shouldn't really be removing material from the plywood, just making
it more bond-able.
Gary's comments refer more to glue joints for end-grain spruce (or whatever softwood
you are building with). When spruce is sawn, the end grain has open pores
which will absorb the adhesive. If the end is sanded (and especially if the
wood gets burned in sanding), the pores tend to get clogged, which impedes the
absorption of the adhesive. If the epoxy doesn't "bite" into the wood, the joint
will not achieve the strength that is needed. That is a bad thing.
So, Ben, if you are asking about sanding the "gluing side" of the plywood gussets,
then, yes you should sand them, like Glenn said. If that's not what you're
asking, then maybe you need to re-state your question more clearly.
Bill C.
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=196540#196540
Message 5
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
Charley
For what its worth I was considering the door also. I was just really concerned
reluctant to cut the upper longeron weakening the structure for an occasional
rider. That thought was reaffirmed by my tech councelor. You may want to reconsider
that also
John
------Original Message------
From: gcardinal
Sender: owner-pietenpol-list-server@matronics.com
ReplyTo: pietenpol-list@matronics.com
Sent: Aug 5, 2008 7:10 AM
Subject: Re: Pietenpol-List: How hard is it to get into the front seat
Charley,
Keri-Ann Price sells plans for a modification to add a door to the passenger
seat. Her website is:
http://www.geocities.com/keriannprice/Pietenpol_Plan_Packages.html
Greg
----- Original Message -----
From: "charles loomis" <rameses32@yahoo.com>
Sent: Tuesday, August 05, 2008 3:48 AM
Subject: Pietenpol-List: How hard is it to get into the front seat
>
> I think I remember seeing a video showing that it was pretty difficult.
> The reason I ask is because my misses is not the most flexible person and
> she has a bad back. I really wish to build a Pietenpol with a Model A
> engine, but I also want to take her flying and show her why there is
> nothing else like it.
> Charley
>
>
>
Sent from my Verizon Wireless BlackBerry
Message 6
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
Charley,
I've found that if a person really wants to get in they will.
I added a step on the rear gear leg that really helps.
Good friend of mine of 35 years, was the last of the people not to get polio
shots.
His legs are shriveled and only 50% there.
But he wanted to get in and he did. Had a great time.
But then he couldn't get out! Me and a friend, grabbed him and lifted him
out.
A fun time was had by all.
Big thing about the Piet that no one had discussed, is the tight room for
your feet on the rudder with a big butt sitting there.
Once had to make up a feeble excuse about the winds aloft, cause I couldn't
take a big-butted lady, who would have loved a ride
walt evans
NX140DL
----- Original Message -----
From: "charles loomis" <rameses32@yahoo.com>
Sent: Tuesday, August 05, 2008 4:48 AM
Subject: Pietenpol-List: How hard is it to get into the front seat
>
> I think I remember seeing a video showing that it was pretty difficult.
> The reason I ask is because my misses is not the most flexible person and
> she has a bad back. I really wish to build a Pietenpol with a Model A
> engine, but I also want to take her flying and show her why there is
> nothing else like it.
> Charley
>
>
>
Message 7
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Homemade Turnbuckles |
Has anyone talked with Frank Pavliga ? His Piet used 3/32 cable to cross angle
support the cabanes, and had to keep tightening because of stretch, and replaced
them after a few hours of flight. Do other applications of 3/32 cable experience
the same problem ? Don't chance it.
Allen Rudolf's piet still flys with 1/8 Th" cables and the plane weights under
640 Lbs. And will fly two people on a 90 Deg. day with a standard Ford A just
turning 1950 RPM.
Pieti Lowell[/quote]
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=196610#196610
Message 8
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Homemade Turnbuckles |
In theory, we should be able to build stronger turnbuckles than standard aircraft
ones. The A/C turnbuckles are made of brass. Their male threads are rolled,
making them stronger than the cut threads we would make. However, I believe
the female (tapped) threads are cut. That would likely be the wekaer link,
and more likely to strip in tension. Moreover, brass is has less tensile and
shering strength than either steel or stainless steel.
Building our own turnbuckles out of stainless steel (female) and a cap bolt (male)
might be the best of all worlds. The high quality steel cap bolt (socket
head) has rolled threads and is case hardened, as well. The mating female part
(homemade) has cut threads, but the S.S. material is much stronger than the
brass. Moreover, the builder might experiment with slightly undersize tap drills
to achieve nearly interference fit (more thread-to-thread surface). This
last step might not be practical, and a real tap-breaker, but perhaps a worthy
experiment.
Also, as in the demontrated design, the homebuilder can make the straps that carry
the loads on the ends of the entire turnbuckle assembly as thick and wide
as needed.
Of course, as stated first in this note... this is only THEORY, and that is why
testing is so important.
If it works, the proper homemade turnbuckle would be not only cheaper, but better
than store-bought aircraft quality. It would also be more in keeping with
the barndoor hinge, baling wire, and oatmeal carton LE heritage of the Piet itself.
Note, though, that this is definitely NOT an appeal for Home Depot turnbuckles.
Tim in central Texas
-----Original Message-----
>From: gcardinal <gcardinal@comcast.net>
>Sent: Aug 5, 2008 6:22 AM
>To: pietenpol-list@matronics.com
>Subject: Re: Pietenpol-List: Homemade Turnbuckles
>
>Bill,
>
>Dale Johnson built a pull tester for testing the cables on NX18235. We also used
it to test some homemade turnbuckle barrels.
>Dale would be happy to do a test on one or more of your turnbuckles.
>Let me know if you are interested.
>
>Greg Cardinal
> ----- Original Message -----
> From: Bill Church
> To: pietenpol-list@matronics.com
> Sent: Thursday, July 31, 2008 12:34 PM
> Subject: RE: Pietenpol-List: Homemade Turnbuckles
>
>
> Ken,
>
> I kind of got sidetracked away from the homemade turnbuckles for a while, and
I've actually been building my tailfeathers. So, the short answer to your question
is "No, I haven't".
> Having said that, here's the long answer.
> I didn't do any strength calculations, but I have a strong feeling that the
turnbuckles as I made them will be sufficient in strength, but I have yet to do
some real-world pull testing to see what they can safely handle. Before I do
the pull test I wanted to refine the design a bit to make them a bit more user
friendly. That way I'll be testing the proper part, not just something similar.
I still plan to do it, just not right now. If you need an answer right now,
I think just about anyone could make up a set of these in a short period of
time, and then do their own testing using a simple apparatus (lever and pivot).
When I do get around to revising the design and doing the pull-testing, I'll
share the results with the list.
> If you want more details about how I made the prototype, let me know.
>
> Bill C.
>
>
>------------------------------------------------------------------------------
> From: owner-pietenpol-list-server@matronics.com [mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of KMHeide, BA, CPO, FAAOP
> Sent: Thursday, July 31, 2008 12:37 PM
> To: pietenpol-list@matronics.com
> Subject: RE: Pietenpol-List: Homemade Turnbuckles
>
>
> Bill,
>
> Have you nailed down the materials (thickness, width, length, rod size,
etc) to manufacture the turnbuckles for the tail section? After seeing the price
for the turnbuckles on Aircraft Spruce and others, I think making my own
would be a great idea... any assistance?
>
>
> Kenneth M. Heide, BA, CPO, FAAOP
>
>
>
Message 9
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Homemade Turnbuckles |
Maybe this would be an area for the CozyGirrrls to make some parts.
There are several dozen turnbuckles required to build a Pietenpol, and
they could offer a turnbuckle kit.
Jack Phillips
NX899JP
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Tim
Willis
Sent: Tuesday, August 05, 2008 10:22 AM
Subject: Re: Pietenpol-List: Homemade Turnbuckles
<timothywillis@earthlink.net>
In theory, we should be able to build stronger turnbuckles than standard
aircraft ones. The A/C turnbuckles are made of brass. Their male
threads are rolled, making them stronger than the cut threads we would
make. However, I believe the female (tapped) threads are cut. That
would likely be the wekaer link, and more likely to strip in tension.
Moreover, brass is has less tensile and shering strength than either
steel or stainless steel.
Building our own turnbuckles out of stainless steel (female) and a cap
bolt (male) might be the best of all worlds. The high quality steel cap
bolt (socket head) has rolled threads and is case hardened, as well.
The mating female part (homemade) has cut threads, but the S.S. material
is much stronger than the brass. Moreover, the builder might experiment
with slightly undersize tap drills to achieve nearly interference fit
(more thread-to-thread surface). This last step might not be practical,
and a real tap-breaker, but perhaps a worthy experiment.
Also, as in the demontrated design, the homebuilder can make the straps
that carry the loads on the ends of the entire turnbuckle assembly as
thick and wide as needed.
Of course, as stated first in this note... this is only THEORY, and that
is why testing is so important.
If it works, the proper homemade turnbuckle would be not only cheaper,
but better than store-bought aircraft quality. It would also be more in
keeping with the barndoor hinge, baling wire, and oatmeal carton LE
heritage of the Piet itself. Note, though, that this is definitely NOT
an appeal for Home Depot turnbuckles.
Tim in central Texas
-----Original Message-----
>From: gcardinal <gcardinal@comcast.net>
>Sent: Aug 5, 2008 6:22 AM
>To: pietenpol-list@matronics.com
>Subject: Re: Pietenpol-List: Homemade Turnbuckles
>
>Bill,
>
>Dale Johnson built a pull tester for testing the cables on NX18235. We
also used it to test some homemade turnbuckle barrels.
>Dale would be happy to do a test on one or more of your turnbuckles.
>Let me know if you are interested.
>
>Greg Cardinal
> ----- Original Message -----
> From: Bill Church
> To: pietenpol-list@matronics.com
> Sent: Thursday, July 31, 2008 12:34 PM
> Subject: RE: Pietenpol-List: Homemade Turnbuckles
>
>
> Ken,
>
> I kind of got sidetracked away from the homemade turnbuckles for a
while, and I've actually been building my tailfeathers. So, the short
answer to your question is "No, I haven't".
> Having said that, here's the long answer.
> I didn't do any strength calculations, but I have a strong feeling
that the turnbuckles as I made them will be sufficient in strength, but
I have yet to do some real-world pull testing to see what they can
safely handle. Before I do the pull test I wanted to refine the design a
bit to make them a bit more user friendly. That way I'll be testing the
proper part, not just something similar. I still plan to do it, just not
right now. If you need an answer right now, I think just about anyone
could make up a set of these in a short period of time, and then do
their own testing using a simple apparatus (lever and pivot). When I do
get around to revising the design and doing the pull-testing, I'll share
the results with the list.
> If you want more details about how I made the prototype, let me know.
>
> Bill C.
>
>
>-----------------------------------------------------------------------
-------
> From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of KMHeide,
BA, CPO, FAAOP
> Sent: Thursday, July 31, 2008 12:37 PM
> To: pietenpol-list@matronics.com
> Subject: RE: Pietenpol-List: Homemade Turnbuckles
>
>
> Bill,
>
> Have you nailed down the materials (thickness, width, length,
rod size, etc) to manufacture the turnbuckles for the tail section?
After seeing the price for the turnbuckles on Aircraft Spruce and
others, I think making my own would be a great idea... any assistance?
>
>
> Kenneth M. Heide, BA, CPO, FAAOP
>
>
>
Message 10
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: fuel drain locations |
Hi Douwe,
I have placed fuel outlets in most locations and finally just use the rear right,
because a boarding passenger will hit the left rear with his shoulder, and
if you fly with the ball in the center either rear locations will work. The center
location, "Allen Rudolf's " will get tagged very often by a passenger boarding.
Pieti Lowell
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=196620#196620
Message 11
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: best movie scenes |
If you want to see some neat Piet flying, take a gander at " Red Betsy ", Ted Davis
did the flights in this movie. Type the title in the search web.
Pieti Lowell
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=196625#196625
Message 12
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Frued table saw blades |
You are quite right, I use a 80 tooth carbide to saw my spars from a 6"X 2-1/2"
X 14 Ft. Lg. Sitkus, when I flipped the beam over and reversed ends the surface
never needed a plane job.
Pieti Lowell
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=196627#196627
Message 13
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Homemade Turnbuckles |
Tim,
Now you've got me re-energized and ready to get back to work on the
turnbuckle prototyping, with a new twist.
I'm going to try making one from oatmeal cartons and stove bolts!
Or not.
Actually there's no need to make them stronger than A/C turnbuckles, just
equal. But the use of higher strength materials (st.st. vs brass) could
allow for some weight savings, based on a strength to weight basis.
Stainless steel will provide necessary corrosion resistance, like brass,
since most of the turnbuckles are exposed to the elements. Using smaller tap
drills will definitely become a source of extreme frustration for anyone
working with stainless steel, and the cost of broken taps will very quickly
exceed the cost of buying A/C turnbuckles.
One feature that I have not yet figured out is a method to safety wire such
a homemade turnbuckle.
I don't actually anticipate doing any further development on my prototypes
until sometime later in the fall, when it gets too cold out in the garage
for epoxy to cure. When I have some results, I'll share them with the list.
But that doesn't mean someone else can't go ahead with their own ideas /
prototypes / testing.
Bill C.
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Tim Willis
Sent: Tuesday, August 05, 2008 10:22 AM
Subject: Re: Pietenpol-List: Homemade Turnbuckles
--> <timothywillis@earthlink.net>
In theory, we should be able to build stronger turnbuckles than standard
aircraft ones. The A/C turnbuckles are made of brass. Their male threads
are rolled, making them stronger than the cut threads we would make.
However, I believe the female (tapped) threads are cut. That would likely
be the wekaer link, and more likely to strip in tension. Moreover, brass is
has less tensile and shering strength than either steel or stainless steel.
Building our own turnbuckles out of stainless steel (female) and a cap bolt
(male) might be the best of all worlds. The high quality steel cap bolt
(socket head) has rolled threads and is case hardened, as well. The mating
female part (homemade) has cut threads, but the S.S. material is much
stronger than the brass. Moreover, the builder might experiment with
slightly undersize tap drills to achieve nearly interference fit (more
thread-to-thread surface). This last step might not be practical, and a
real tap-breaker, but perhaps a worthy experiment.
Also, as in the demontrated design, the homebuilder can make the straps that
carry the loads on the ends of the entire turnbuckle assembly as thick and
wide as needed.
Of course, as stated first in this note... this is only THEORY, and that is
why testing is so important.
If it works, the proper homemade turnbuckle would be not only cheaper, but
better than store-bought aircraft quality. It would also be more in keeping
with the barndoor hinge, baling wire, and oatmeal carton LE heritage of the
Piet itself. Note, though, that this is definitely NOT an appeal for Home
Depot turnbuckles.
Tim in central Texas
Message 14
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
Chet,
Have you:
Set timing at 28 Deg ?
Cleaned the casting out from the water inlet with a stiff wire ?
Use a Ford T water pump in place of the A pump ?
Check head gasket and H2O openings.in castings ?
Radiator clean and large enough ?
Auto fuel ?
I run a Ford B supped- up to 90 HP and when it ran hot,In the water pump I found
one impeller of two broke off, welded it on, solved problem, I use a Funk pump,
externally mounted, like the "T" pump, which I have used in the past with
success.
Pieti Lowell
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=196633#196633
Message 15
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Homemade Turnbuckles |
Bill, you won't need to safety wire them-- use oatmeal itself as "loctite."
Tim
Do not archive
-----Original Message-----
>From: Bill Church <eng@canadianrogers.com>
>Sent: Aug 5, 2008 10:20 AM
>To: pietenpol-list@matronics.com
>Subject: RE: Pietenpol-List: Homemade Turnbuckles
>
>Tim,
>
>Now you've got me re-energized and ready to get back to work on the
>turnbuckle prototyping, with a new twist.
>I'm going to try making one from oatmeal cartons and stove bolts!
>
>Or not.
>
>Actually there's no need to make them stronger than A/C turnbuckles, just
>equal. But the use of higher strength materials (st.st. vs brass) could
>allow for some weight savings, based on a strength to weight basis.
>Stainless steel will provide necessary corrosion resistance, like brass,
>since most of the turnbuckles are exposed to the elements. Using smaller tap
>drills will definitely become a source of extreme frustration for anyone
>working with stainless steel, and the cost of broken taps will very quickly
>exceed the cost of buying A/C turnbuckles.
>
>One feature that I have not yet figured out is a method to safety wire such
>a homemade turnbuckle.
>
>I don't actually anticipate doing any further development on my prototypes
>until sometime later in the fall, when it gets too cold out in the garage
>for epoxy to cure. When I have some results, I'll share them with the list.
>But that doesn't mean someone else can't go ahead with their own ideas /
>prototypes / testing.
>
>Bill C.
>
>
>
>-----Original Message-----
>From: owner-pietenpol-list-server@matronics.com
>[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Tim Willis
>Sent: Tuesday, August 05, 2008 10:22 AM
>To: pietenpol-list@matronics.com
>Subject: Re: Pietenpol-List: Homemade Turnbuckles
>
>--> <timothywillis@earthlink.net>
>
>In theory, we should be able to build stronger turnbuckles than standard
>aircraft ones. The A/C turnbuckles are made of brass. Their male threads
>are rolled, making them stronger than the cut threads we would make.
>However, I believe the female (tapped) threads are cut. That would likely
>be the wekaer link, and more likely to strip in tension. Moreover, brass is
>has less tensile and shering strength than either steel or stainless steel.
>
>
>Building our own turnbuckles out of stainless steel (female) and a cap bolt
>(male) might be the best of all worlds. The high quality steel cap bolt
>(socket head) has rolled threads and is case hardened, as well. The mating
>female part (homemade) has cut threads, but the S.S. material is much
>stronger than the brass. Moreover, the builder might experiment with
>slightly undersize tap drills to achieve nearly interference fit (more
>thread-to-thread surface). This last step might not be practical, and a
>real tap-breaker, but perhaps a worthy experiment.
>
>Also, as in the demontrated design, the homebuilder can make the straps that
>carry the loads on the ends of the entire turnbuckle assembly as thick and
>wide as needed.
>
>Of course, as stated first in this note... this is only THEORY, and that is
>why testing is so important.
>
>If it works, the proper homemade turnbuckle would be not only cheaper, but
>better than store-bought aircraft quality. It would also be more in keeping
>with the barndoor hinge, baling wire, and oatmeal carton LE heritage of the
>Piet itself. Note, though, that this is definitely NOT an appeal for Home
>Depot turnbuckles.
>
>Tim in central Texas
Message 16
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | ribs and ailerons |
Afternoon Group,
Here's a question... Once all 31 ribs are made how many of the ribs need to be
set aside for the ailerons?
73,
Ben in MN
Message 17
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: ribs and ailerons |
Ben,
Check the plans, the ailerons are built integral with the wing and
cut out after you have completed building & trammeling the wing. I'm
not there yet, but maybe someone else on the list can expain the
process.
Kip Gardner
On Aug 5, 2008, at 12:20 PM, Ben Ramler wrote:
> <ben_ramler2002@yahoo.com>
>
> Afternoon Group,
> Here's a question... Once all 31 ribs are made how many of the
> ribs need to be set aside for the ailerons?
> 73,
> Ben in MN
>
>
Message 18
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Homemade Turnbuckles |
-----Original Message-----
>From: Tim Willis <timothywillis@earthlink.net>
>Sent: Aug 5, 2008 9:21 AM
>To: pietenpol-list@matronics.com
>Subject: Re: Pietenpol-List: Homemade Turnbuckles
>
>
>In theory, we should be able to build stronger turnbuckles than standard aircraft
ones. The A/C turnbuckles are made of brass. Their male threads are rolled,
making them stronger than the cut threads we would make. However, I believe
the female (tapped) threads are cut. That would likely be the wekaer link,
and more likely to strip in tension. Moreover, brass is has less tensile and
shering strength than either steel or stainless steel.
Tim,
I also thought this was the case regarding the SS turnbuckles, but check out the
ones that McMaster-Carr sells:
http://www.mcmaster.com/ p/n 3082T21
These are SS turnbuckles comparable to the AN130-16S that AS&S sells, but they
are longer. For some reason the SS turnbuckles at McMaster are rated at 400lbs
whereas the AN130-16S are rated at 1600lbs. I don't understand how the brass
turnbuckles could be 4X as strong as the SS but perhaps some of the mechanical
gurus can enlighten us. It may be the type of SS that is used, or perhaps
the eyelet is not welded. That said, I would think 400lbs would be plenty strong
for a low & slow Aircamper. BTW, the AN130-16S sells for about $27 and the
McMaster SS one is just over $17.
Regards,
John F.
Richmond, TX (Eduordo was a bust!)
GN-1 Aircamper
Corvair 164cid
________________________________________
Message 19
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Model A mag timing |
Lowell,
I have my mags set to 30 degrees, per what Ken Perkins recommends. What do
you think?
Dan Helsper
Poplar Grove, IL.
**************Looking for a car that's sporty, fun and fits in your budget?
Read reviews on AOL Autos.
(http://autos.aol.com/cars-BMW-128-2008/expert-review?ncid=aolaut00050000000017 )
Message 20
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | ribs and ailerons |
Count them. You do have the plans, don't you?
Jack Phillips
NX899JP
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com [mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 12:21 PM
Subject: Pietenpol-List: ribs and ailerons
Afternoon Group,
Here's a question... Once all 31 ribs are made how many of the ribs need to be
set aside for the ailerons?
73,
Ben in MN
Message 21
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
William Wynne told me the ready to fly weight of the Corvair including wood
prop and around 6 lbs for a mount comes to 240 lbs (with starter). Sounds
like yours will come to more than that.
Rick
On Mon, Aug 4, 2008 at 6:21 PM, skellytown flyer <rhano@att.net> wrote:
>
> yes the weight did include oil in the case.,but not the carb or the exhaust
> stacks except the cast iron headers.
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=196521#196521
>
>
--
Rick Holland
Castle Rock, Colorado
Message 22
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | ribs and ailerons |
Ben I built the entire wing except for the wing tip bow, diagonals and
plywood leading edge covering. then I made up the three airleron spars and
slid them into place from the wing end and glued them in with T-88. The wing
has to be square when this is done. I used the plumb bob method which is
described at the top of page 66 of the " EAA Aircraft building Techniques
WOOD" book checking the alighnment continuously during construction. If you
don't have one it is available through EAA book store and well worth it but
there are other methods of squareing the wing. I did one set of airleron
spars with the wing verticle as shown in the book and the other wing
horizontal on saw horses, the horizontal one was much easier to work with.
All 30 ribs are identicle thanks to the genious of Mr. B. Pietenpol but the
airleron spars only pick up the outer six/seven. Once the airleron spars
were glued in I used my rib jig to make the inside end rib for the airleron.
I used the wing tip bow to mark the airleron spar ends and carefully cut
them to match up to the tip bow with a good sharp box saw. I then glued on
the wing tip bow, the airleron diagonals. the inner end blocking and even
installed my airleron hinges. I then cut the airleron free with my box saw.
since it was part of the wing when it was built it fits perfectly. This is
the way I did it and it worked perfectly I'm sure there are other valuable
opinions from people on the list. Hope this helps.
Ed Grentzer
>From: Ben Ramler <ben_ramler2002@yahoo.com>
>To: pietenpol-list@matronics.com
>Subject: Pietenpol-List: ribs and ailerons
>Date: Tue, 5 Aug 2008 09:20:38 -0700 (PDT)
>
>
>Afternoon Group,
> Here's a question... Once all 31 ribs are made how many of the ribs
>need to be set aside for the ailerons?
>73,
>Ben in MN
>
>
Message 23
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Homemade Turnbuckles |
I made my own turnbuckles. They are a pain to adjust, but strong -- pull tested
to almost 2000# when the test rig broke.
Tom Bernie
GN-1 Gloucester Mass
-----Original Message-----
>From: Tim Willis <timothywillis@earthlink.net>
>Sent: Aug 5, 2008 11:35 AM
>To: pietenpol-list@matronics.com
>Subject: RE: Pietenpol-List: Homemade Turnbuckles
>
>
>Bill, you won't need to safety wire them-- use oatmeal itself as "loctite."
>Tim
>Do not archive
>
>-----Original Message-----
>>From: Bill Church <eng@canadianrogers.com>
>>Sent: Aug 5, 2008 10:20 AM
>>To: pietenpol-list@matronics.com
>>Subject: RE: Pietenpol-List: Homemade Turnbuckles
>>
>>Tim,
>>
>>Now you've got me re-energized and ready to get back to work on the
>>turnbuckle prototyping, with a new twist.
>>I'm going to try making one from oatmeal cartons and stove bolts!
>>
>>Or not.
>>
>>Actually there's no need to make them stronger than A/C turnbuckles, just
>>equal. But the use of higher strength materials (st.st. vs brass) could
>>allow for some weight savings, based on a strength to weight basis.
>>Stainless steel will provide necessary corrosion resistance, like brass,
>>since most of the turnbuckles are exposed to the elements. Using smaller tap
>>drills will definitely become a source of extreme frustration for anyone
>>working with stainless steel, and the cost of broken taps will very quickly
>>exceed the cost of buying A/C turnbuckles.
>>
>>One feature that I have not yet figured out is a method to safety wire such
>>a homemade turnbuckle.
>>
>>I don't actually anticipate doing any further development on my prototypes
>>until sometime later in the fall, when it gets too cold out in the garage
>>for epoxy to cure. When I have some results, I'll share them with the list.
>>But that doesn't mean someone else can't go ahead with their own ideas /
>>prototypes / testing.
>>
>>Bill C.
>>
>>
>>
>>-----Original Message-----
>>From: owner-pietenpol-list-server@matronics.com
>>[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Tim Willis
>>Sent: Tuesday, August 05, 2008 10:22 AM
>>To: pietenpol-list@matronics.com
>>Subject: Re: Pietenpol-List: Homemade Turnbuckles
>>
>>--> <timothywillis@earthlink.net>
>>
>>In theory, we should be able to build stronger turnbuckles than standard
>>aircraft ones. The A/C turnbuckles are made of brass. Their male threads
>>are rolled, making them stronger than the cut threads we would make.
>>However, I believe the female (tapped) threads are cut. That would likely
>>be the wekaer link, and more likely to strip in tension. Moreover, brass is
>>has less tensile and shering strength than either steel or stainless steel.
>>
>>
>>Building our own turnbuckles out of stainless steel (female) and a cap bolt
>>(male) might be the best of all worlds. The high quality steel cap bolt
>>(socket head) has rolled threads and is case hardened, as well. The mating
>>female part (homemade) has cut threads, but the S.S. material is much
>>stronger than the brass. Moreover, the builder might experiment with
>>slightly undersize tap drills to achieve nearly interference fit (more
>>thread-to-thread surface). This last step might not be practical, and a
>>real tap-breaker, but perhaps a worthy experiment.
>>
>>Also, as in the demontrated design, the homebuilder can make the straps that
>>carry the loads on the ends of the entire turnbuckle assembly as thick and
>>wide as needed.
>>
>>Of course, as stated first in this note... this is only THEORY, and that is
>>why testing is so important.
>>
>>If it works, the proper homemade turnbuckle would be not only cheaper, but
>>better than store-bought aircraft quality. It would also be more in keeping
>>with the barndoor hinge, baling wire, and oatmeal carton LE heritage of the
>>Piet itself. Note, though, that this is definitely NOT an appeal for Home
>>Depot turnbuckles.
>>
>>Tim in central Texas
>
>
Message 24
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
walt,
How big-butted are you talking about here?
Furthermore, is the Piet a truly capable 2-seater at all?
--------
Location: Eastern N.C.
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=196707#196707
Message 25
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
Tom,
There is a saying that you may not have heard since you are fairly
new to the list - "This plane was designed when midgets ruled the
earth!" Bernard, by all accounts, was about 5'4" and weighed maybe
140 lbs. Now that's just about my size, and my wife is about the
same, and our daughter will probably be about equal or less as an
adult, so for us, yes, it's a capable 2-seater. Heck, we could even
carry 50-60 lbs of baggage if there was space for it! For two 200+
lb. guys, add in a full load of fuel and you're close to gross, if
not over, depending on how light or heavy you built your plane.
Kip G.
On Aug 5, 2008, at 2:48 PM, Tom Anderson wrote:
> <tomanderson_nc@yahoo.com>
>
> walt,
> How big-butted are you talking about here?
> Furthermore, is the Piet a truly capable 2-seater at all?
>
> --------
> Location: Eastern N.C.
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=196707#196707
>
>
Message 26
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: ribs and ailerons |
yes at least page 1 page.
----- Original Message ----
From: "Phillips, Jack" <Jack.Phillips@cardinalhealth.com>
Sent: Tuesday, August 5, 2008 12:03:57 PM
Subject: RE: Pietenpol-List: ribs and ailerons
Count them. You do have the plans, don't you?
Jack Phillips
NX899JP
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com [mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 12:21 PM
Subject: Pietenpol-List: ribs and ailerons
Afternoon Group,
Here's a question... Once all 31 ribs are made how many of the ribs need to be
set aside for the ailerons?
73,
Ben in MN
Message 27
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: ribs and ailerons |
not sure where the rest of the plans went to though. I have hard time reading plans
though to be honest.
----- Original Message ----
From: "Phillips, Jack" <Jack.Phillips@cardinalhealth.com>
Sent: Tuesday, August 5, 2008 12:03:57 PM
Subject: RE: Pietenpol-List: ribs and ailerons
Count them. You do have the plans, don't you?
Jack Phillips
NX899JP
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com [mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 12:21 PM
Subject: Pietenpol-List: ribs and ailerons
Afternoon Group,
Here's a question... Once all 31 ribs are made how many of the ribs need to be
set aside for the ailerons?
73,
Ben in MN
Message 28
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | ribs and ailerons |
Yikes!
Ben, what are you doing trying to build a plane without having or reading
the plans???
The plans is all there is.
There ain't no other way to do it.
Maybe it's time to order a new set of plans (or put the project to rest).
Or are you just pulling our collective leg?
Bill C.
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 5:08 PM
Subject: Re: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
not sure where the rest of the plans went to though. I have hard time
reading plans though to be honest.
----- Original Message ----
From: "Phillips, Jack" <Jack.Phillips@cardinalhealth.com>
Sent: Tuesday, August 5, 2008 12:03:57 PM
Subject: RE: Pietenpol-List: ribs and ailerons
--> <Jack.Phillips@cardinalhealth.com>
Count them. You do have the plans, don't you?
Jack Phillips
NX899JP
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 12:21 PM
Subject: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
Afternoon Group,
Here's a question... Once all 31 ribs are made how many of the ribs need
to be set aside for the ailerons?
73,
Ben in MN
Message 29
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
Build light!
Somewhere I once saw "Simplicate and add lightness!"
Just for some numbers, I have an A-65 Continental and it weighs in at 626lbs. empty.
Full fuel is just under 15 gallons. I regularly carry a 230lb. passenger
with full fuel and me at nearly 185 lbs. It doesn't exactly claw for altitude
at that weight, but basically I know if I can get the passenger into the front
hole I can lift them out of a respectable field.
Don Emch
NX899DE
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=196754#196754
Message 30
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
Just thought I'd throw this picture in from a week or so ago, somewhere in Ohio...
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=196756#196756
Attachments:
http://forums.matronics.com//files/flying_circus00541_181.jpg
Message 31
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Model A mag timing |
Should work great, even without an impulse. Max RPM is the results, In the olden
days 73 Oct. was max. Then 25 Deg. is what most mfg. recommended. Keep plugs
at .015"/.018" or it is hard starting.
Pieti Lowell
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=196757#196757
Message 32
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
Absolutely a two seater.
Had my 190 pounder brother-in law up today. and I weigh 210#
But you have to build light.
My empty weight was at 595#. With us and gas, still climbs like crazy.
Look at this youtube. with Don at 180#
http://www.youtube.com/watch?v=CLrIDeDLR48
No white knuckles at all.
Build light
build light
build light
walt evans
NX140DL
----- Original Message -----
From: "Tom Anderson" <tomanderson_nc@yahoo.com>
Sent: Tuesday, August 05, 2008 2:48 PM
Subject: Pietenpol-List: Re: How hard is it to get into the front seat
> <tomanderson_nc@yahoo.com>
>
> walt,
> How big-butted are you talking about here?
> Furthermore, is the Piet a truly capable 2-seater at all?
>
> --------
> Location: Eastern N.C.
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=196707#196707
>
>
>
Message 33
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
Has anybody done the door mod with a tube-and-fabric fuselage instead of a wooden
one?
Jim Ash
-----Original Message-----
>From: gcardinal <gcardinal@comcast.net>
>Sent: Aug 5, 2008 7:10 AM
>To: pietenpol-list@matronics.com
>Subject: Re: Pietenpol-List: How hard is it to get into the front seat
>
>
>Charley,
>
>Keri-Ann Price sells plans for a modification to add a door to the passenger
>seat. Her website is:
>
>http://www.geocities.com/keriannprice/Pietenpol_Plan_Packages.html
>
>Greg
>
>----- Original Message -----
>From: "charles loomis" <rameses32@yahoo.com>
>To: <pietenpol-list@matronics.com>
>Sent: Tuesday, August 05, 2008 3:48 AM
>Subject: Pietenpol-List: How hard is it to get into the front seat
>
>
>>
>> I think I remember seeing a video showing that it was pretty difficult.
>> The reason I ask is because my misses is not the most flexible person and
>> she has a bad back. I really wish to build a Pietenpol with a Model A
>> engine, but I also want to take her flying and show her why there is
>> nothing else like it.
>> Charley
>>
>>
>>
>>
>>
>>
>>
>>
>>
>>
>
>
Message 34
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Just for kicks |
I love those colors. :^))
walt evans
NX140DL
----- Original Message -----
From: "Don Emch" <EmchAir@aol.com>
Sent: Tuesday, August 05, 2008 6:05 PM
Subject: Pietenpol-List: Just for kicks
>
> Just thought I'd throw this picture in from a week or so ago, somewhere in
> Ohio...
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=196756#196756
>
>
> Attachments:
>
> http://forums.matronics.com//files/flying_circus00541_181.jpg
>
>
>
Message 35
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: ribs and ailerons |
nope. Dad said the flyer and glider manual is what to use.
----- Original Message ----
From: Bill Church <eng@canadianrogers.com>
Sent: Tuesday, August 5, 2008 4:39:04 PM
Subject: RE: Pietenpol-List: ribs and ailerons
Yikes!
Ben, what are you doing trying to build a plane without having or reading
the plans???
The plans is all there is.
There ain't no other way to do it.
Maybe it's time to order a new set of plans (or put the project to rest).
Or are you just pulling our collective leg?
Bill C.
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 5:08 PM
Subject: Re: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
not sure where the rest of the plans went to though. I have hard time
reading plans though to be honest.
----- Original Message ----
From: "Phillips, Jack" <Jack.Phillips@cardinalhealth.com>
Sent: Tuesday, August 5, 2008 12:03:57 PM
Subject: RE: Pietenpol-List: ribs and ailerons
--> <Jack.Phillips@cardinalhealth.com>
Count them. You do have the plans, don't you?
Jack Phillips
NX899JP
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 12:21 PM
Subject: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
Afternoon Group,
Here's a question... Once all 31 ribs are made how many of the ribs need
to be set aside for the ailerons?
73,
Ben in MN
Message 36
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: ribs and ailerons |
you have 150 to spend??? I don't!
----- Original Message ----
From: Bill Church <eng@canadianrogers.com>
Sent: Tuesday, August 5, 2008 4:39:04 PM
Subject: RE: Pietenpol-List: ribs and ailerons
Yikes!
Ben, what are you doing trying to build a plane without having or reading
the plans???
The plans is all there is.
There ain't no other way to do it.
Maybe it's time to order a new set of plans (or put the project to rest).
Or are you just pulling our collective leg?
Bill C.
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 5:08 PM
Subject: Re: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
not sure where the rest of the plans went to though. I have hard time
reading plans though to be honest.
----- Original Message ----
From: "Phillips, Jack" <Jack.Phillips@cardinalhealth.com>
Sent: Tuesday, August 5, 2008 12:03:57 PM
Subject: RE: Pietenpol-List: ribs and ailerons
--> <Jack.Phillips@cardinalhealth.com>
Count them. You do have the plans, don't you?
Jack Phillips
NX899JP
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 12:21 PM
Subject: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
Afternoon Group,
Here's a question... Once all 31 ribs are made how many of the ribs need
to be set aside for the ailerons?
73,
Ben in MN
Message 37
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | ribs and ailerons |
Ben, Ben, Ben.
Yes, it is possible to build an Air Camper from the Flying and Glider Manual
drawings. I wouldn't want to, but it's been done. Those drawings are so
small I find them pretty hard to read, though. Nonetheless, those are your
plans. I assume you "splurged" for the $8 for the EAA reprint of the FGM.
Use those plans to deternmine how many ribs are affected by the ailerons.
As for $150 being too much to spend, how do you plan to build the rest of
the plane if $150 for a set of plans is too much money? How are you going to
come up with the cash for a motor? How about a propellor? Wheels?
Instruments? The cheapest recent build that I can recall hearing about was
around $5,000. Assuming someone gave you all of the materials to build the
plane, and you live on a property big enough to have your own runway, what
are you going to do when it comes time to fill the tank at $5 a gallon (or
more)? The Pietenpol is one of the most economical "real" aircraft you can
build. It can be built cheaply, but it still ain't free.
Building an airplane from plans drawn in 1934 is a challenge.
Building an airplane without using those plans, and not spending any money
is called dreaming.
Pleasant dreams, Ben.
BC
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 6:30 PM
Subject: Re: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
nope. Dad said the flyer and glider manual is what to use.
you have 150 to spend??? I don't!
----- Original Message ----
From: Bill Church <eng@canadianrogers.com>
Sent: Tuesday, August 5, 2008 4:39:04 PM
Subject: RE: Pietenpol-List: ribs and ailerons
--> <eng@canadianrogers.com>
Yikes!
Ben, what are you doing trying to build a plane without having or reading
the plans???
The plans is all there is.
There ain't no other way to do it.
Maybe it's time to order a new set of plans (or put the project to rest).
Or are you just pulling our collective leg?
Bill C.
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 5:08 PM
Subject: Re: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
not sure where the rest of the plans went to though. I have hard time
reading plans though to be honest.
----- Original Message ----
From: "Phillips, Jack" <Jack.Phillips@cardinalhealth.com>
Sent: Tuesday, August 5, 2008 12:03:57 PM
Subject: RE: Pietenpol-List: ribs and ailerons
--> <Jack.Phillips@cardinalhealth.com>
Count them. You do have the plans, don't you?
Jack Phillips
NX899JP
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 12:21 PM
Subject: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
Afternoon Group,
Here's a question... Once all 31 ribs are made how many of the ribs need
to be set aside for the ailerons?
73,
Ben in MN
Message 38
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
Lowell,
I have had the radiator checked, my timing is 28 degrees but I plan to try
30 degrees. My waster inlet looks to be clean, and I'm runing 100LL. My pump
looks to be in excellent shape, I just replaced the head gasket.
How can you tell a Model T waster pump from a Model A?
Does any one know if Don Hicks used a T or A water pump?
Chet
----- Original Message -----
From: "Pieti Lowell" <Lowellcfrank@yahoo.com>
Sent: Tuesday, August 05, 2008 10:27 AM
Subject: Pietenpol-List: Re: Roll Call
> <Lowellcfrank@yahoo.com>
>
> Chet,
> Have you:
> Set timing at 28 Deg ?
> Cleaned the casting out from the water inlet with a stiff wire ?
> Use a Ford T water pump in place of the A pump ?
> Check head gasket and H2O openings.in castings ?
> Radiator clean and large enough ?
> Auto fuel ?
> I run a Ford B supped- up to 90 HP and when it ran hot,In the water pump I
> found one impeller of two broke off, welded it on, solved problem, I use a
> Funk pump, externally mounted, like the "T" pump, which I have used in the
> past with success.
> Pieti Lowell
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=196633#196633
>
>
>
Message 39
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
And the long fuselage version gives you a bit more cockpit length and you
can always widen the fuselage as many have done (widened mine two inches).
Of course that doesn't necessarily increase your gross weight.
Rick
On Tue, Aug 5, 2008 at 1:01 PM, Kip and Beth Gardner <
kipandbeth@earthlink.net> wrote:
> kipandbeth@earthlink.net>
>
> Tom,
>
> There is a saying that you may not have heard since you are fairly new to
> the list - "This plane was designed when midgets ruled the earth!" Bernard,
> by all accounts, was about 5'4" and weighed maybe 140 lbs. Now that's just
> about my size, and my wife is about the same, and our daughter will probably
> be about equal or less as an adult, so for us, yes, it's a capable 2-seater.
> Heck, we could even carry 50-60 lbs of baggage if there was space for it!
> For two 200+ lb. guys, add in a full load of fuel and you're close to gross,
> if not over, depending on how light or heavy you built your plane.
>
> Kip G.
>
> On Aug 5, 2008, at 2:48 PM, Tom Anderson wrote:
>
>> tomanderson_nc@yahoo.com>
>>
>> walt,
>> How big-butted are you talking about here?
>> Furthermore, is the Piet a truly capable 2-seater at all?
>>
>> --------
>> Location: Eastern N.C.
>>
>>
>>
>>
>> Read this topic online here:
>>
>> http://forums.matronics.com/viewtopic.php?p=196707#196707
>>
>>
>>
>>
>>
>>
>>
>>
>>
>>
>>
>
>
--
Rick Holland
Castle Rock, Colorado
Message 40
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Just for kicks |
Looks just as beautiful in Ohio as it did at Broadhead.
Rick
On Tue, Aug 5, 2008 at 4:05 PM, Don Emch <EmchAir@aol.com> wrote:
>
> Just thought I'd throw this picture in from a week or so ago, somewhere in
> Ohio...
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=196756#196756
>
>
> Attachments:
>
> http://forums.matronics.com//files/flying_circus00541_181.jpg
>
>
--
Rick Holland
Castle Rock, Colorado
Message 41
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
And to look at it from the other perspective, my Pietenpol is very close to
Don's in most respects (65 Continental, wire wheels), but mine is heavy,
weighing 745 lbs empty. I also carry 15 gallons of fuel, and I weigh 200.
I can carry passengers as heavy as 205 - as long as I'm flying off a 6,000'
runway. Climb rate on a hot day with a 200 lb passenger is somewhere around
100 fpm, +/- 90 fpm.
My home field is 2,000' long and I will NOT carry passengers out of it. You
midwesterners don't know how good you've got it. When you say a strip is
2,000' long, you fail to mention that that is the RUNWAY length, but that
the approaches are long and flat and you can fly a mile before you hit
anything. In North Carolina, when we say a runway is 2,000 long, that means
after 2,000' you come to the 100' tall trees. You've got to be able to get
off the ground and then CLIMB! I've done the calculations, and if I lift
off after a 400' roll, that means I've got 1600' to climb 100'. At 50 mph
I'll cover that 1600' in 21.8 seconds, and in that 21.8 seconds at 200 fpm I
will climb exactly 72 feet. Would I carry passengers out of a short field
in the Midwest? I did it at Brodhead and got about that much climb rate.
Will I do it at home? No thanks - I'll fly 15 miles and meet them at
Sanford, with a 6,000' runway and approaches similar to Wisconsin.
Jack Phillips
NX899JP
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Don Emch
Sent: Tuesday, August 05, 2008 5:59 PM
Subject: Pietenpol-List: Re: How hard is it to get into the front seat
Build light!
Somewhere I once saw "Simplicate and add lightness!"
Just for some numbers, I have an A-65 Continental and it weighs in at
626lbs. empty. Full fuel is just under 15 gallons. I regularly carry a
230lb. passenger with full fuel and me at nearly 185 lbs. It doesn't
exactly claw for altitude at that weight, but basically I know if I can get
the passenger into the front hole I can lift them out of a respectable
field.
Don Emch
NX899DE
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=196754#196754
Message 42
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
So would the Model A pull the pietenpol along safely with 320 lbs of humans + fuel?
"I say it that way so I don't get in trouble for telling the misses weight."
hehe
--- On Wed, 8/6/08, Don Emch <EmchAir@aol.com> wrote:
> From: Don Emch <EmchAir@aol.com>
> Subject: Pietenpol-List: Re: How hard is it to get into the front seat
> To: pietenpol-list@matronics.com
> Date: Wednesday, August 6, 2008, 7:59 AM
> Emch" <EmchAir@aol.com>
>
> Build light!
>
> Somewhere I once saw "Simplicate and add
> lightness!"
>
> Just for some numbers, I have an A-65 Continental and it
> weighs in at 626lbs. empty. Full fuel is just under 15
> gallons. I regularly carry a 230lb. passenger with full
> fuel and me at nearly 185 lbs. It doesn't exactly claw
> for altitude at that weight, but basically I know if I can
> get the passenger into the front hole I can lift them out of
> a respectable field.
>
> Don Emch
> NX899DE
>
>
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=196754#196754
>
>
>
>
>
>
>
> http://www.matronics.com/Navigator?Pietenpol-List
Message 43
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
Hey Jack,
Same considerations down here in Georgia. 2000' means up and out and
on top of it ALL in 2000'.
This and other considerations (heat, humidity, too much BBQ) explains
the puckered look of most pilot seats in Piets from the South... ;)
Lotta sphincter muscles workin' over time down here on hot days in Piets...
Jeff
At 8:20 PM -0400 8/5/08, Jack Phillips wrote:
>
>And to look at it from the other perspective, my Pietenpol is very close to
>Don's in most respects (65 Continental, wire wheels), but mine is heavy,
>weighing 745 lbs empty. I also carry 15 gallons of fuel, and I weigh 200.
>I can carry passengers as heavy as 205 - as long as I'm flying off a 6,000'
>runway. Climb rate on a hot day with a 200 lb passenger is somewhere around
>100 fpm, +/- 90 fpm.
>
>My home field is 2,000' long and I will NOT carry passengers out of it. You
>midwesterners don't know how good you've got it. When you say a strip is
>2,000' long, you fail to mention that that is the RUNWAY length, but that
>the approaches are long and flat and you can fly a mile before you hit
>anything. In North Carolina, when we say a runway is 2,000 long, that means
>after 2,000' you come to the 100' tall trees. You've got to be able to get
>off the ground and then CLIMB! I've done the calculations, and if I lift
>off after a 400' roll, that means I've got 1600' to climb 100'. At 50 mph
>I'll cover that 1600' in 21.8 seconds, and in that 21.8 seconds at 200 fpm I
>will climb exactly 72 feet. Would I carry passengers out of a short field
>in the Midwest? I did it at Brodhead and got about that much climb rate.
>Will I do it at home? No thanks - I'll fly 15 miles and meet them at
>Sanford, with a 6,000' runway and approaches similar to Wisconsin.
>
>Jack Phillips
>NX899JP
>
>-----Original Message-----
>From: owner-pietenpol-list-server@matronics.com
>[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Don Emch
>Sent: Tuesday, August 05, 2008 5:59 PM
>To: pietenpol-list@matronics.com
>Subject: Pietenpol-List: Re: How hard is it to get into the front seat
>
>
>Build light!
>
>Somewhere I once saw "Simplicate and add lightness!"
>
>Just for some numbers, I have an A-65 Continental and it weighs in at
>626lbs. empty. Full fuel is just under 15 gallons. I regularly carry a
>230lb. passenger with full fuel and me at nearly 185 lbs. It doesn't
>exactly claw for altitude at that weight, but basically I know if I can get
>the passenger into the front hole I can lift them out of a respectable
>field.
>
>Don Emch
>NX899DE
>
>
>Read this topic online here:
>
>http://forums.matronics.com/viewtopic.php?p=196754#196754
>
>
--
---
Jeffrey H. Boatright, Ph.D.
Associate Professor of Ophthalmology
Emory University School of Medicine
Editor-in-Chief
Molecular Vision
Message 44
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: How hard is it to get into the front seat |
One of the old Buckeye Association newsletters (back in the days when
Frank pavliga was the editor, I think) had a drawing on a way to do
this.
Kip G.
On Aug 5, 2008, at 6:22 PM, Jim Ash wrote:
>
> Has anybody done the door mod with a tube-and-fabric fuselage
> instead of a wooden one?
>
> Jim Ash
>
> -----Original Message-----
>> From: gcardinal <gcardinal@comcast.net>
>> Sent: Aug 5, 2008 7:10 AM
>> To: pietenpol-list@matronics.com
>> Subject: Re: Pietenpol-List: How hard is it to get into the front
>> seat
>>
>> <gcardinal@comcast.net>
>>
>> Charley,
>>
>> Keri-Ann Price sells plans for a modification to add a door to the
>> passenger
>> seat. Her website is:
>>
>> http://www.geocities.com/keriannprice/Pietenpol_Plan_Packages.html
>>
>> Greg
>>
>> ----- Original Message -----
>> From: "charles loomis" <rameses32@yahoo.com>
>> To: <pietenpol-list@matronics.com>
>> Sent: Tuesday, August 05, 2008 3:48 AM
>> Subject: Pietenpol-List: How hard is it to get into the front seat
>>
>>
>>> <rameses32@yahoo.com>
>>>
>>> I think I remember seeing a video showing that it was pretty
>>> difficult.
>>> The reason I ask is because my misses is not the most flexible
>>> person and
>>> she has a bad back. I really wish to build a Pietenpol with a
>>> Model A
>>> engine, but I also want to take her flying and show her why there is
>>> nothing else like it.
>>> Charley
>>>
>>>
>>>
>>>
>>>
>>>
>>>
>>>
>>>
>>>
>>
>>
>>
>>
>>
>
>
Message 45
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Homemade Turnbuckles |
NX18235 has 3/32 cables bracing the cabanes. No adjustments needed in 140
hours of flying.
Greg
----- Original Message -----
From: "Pieti Lowell" <Lowellcfrank@yahoo.com>
Sent: Tuesday, August 05, 2008 9:04 AM
Subject: Pietenpol-List: Re: Homemade Turnbuckles
> <Lowellcfrank@yahoo.com>
>
> Has anyone talked with Frank Pavliga ? His Piet used 3/32 cable to cross
> angle support the cabanes, and had to keep tightening because of stretch,
> and replaced them after a few hours of flight. Do other applications of
> 3/32 cable experience the same problem ? Don't chance it.
> Allen Rudolf's piet still flys with 1/8 Th" cables and the plane weights
> under 640 Lbs. And will fly two people on a 90 Deg. day with a standard
> Ford A just turning 1950 RPM.
> Pieti Lowell[/quote]
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=196610#196610
>
>
>
Message 46
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
Does anyone have a intercom installed? I tried a portable Sigtronics
and it didnt work, it kept the mic open because of wind noise. I'm
thinking it might work if I installed a PTT in the front cockpit and we
talked but broadcast the conversation, but I dont want that.
Dick N.
Message 47
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
Dick,
I use an HM200 (http://www.ozpilot.com.au/cgi-bin/webitempage.pl?hm200).
There is a fair amount of wind noise but I put some large foam covers over
the microphone (ala Sports Commentators) and that stops some of it. It also
plugs nicely into the Icom hand held.
Cheers
Peter
Wonthaggi Australia
http://www.cpc-world.com <http://www.cpc-world.com/>
_____
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Dick
Navratil
Sent: Wednesday, 6 August 2008 2:14 PM
Subject: Pietenpol-List: intercom
Does anyone have a intercom installed? I tried a portable Sigtronics and it
didnt work, it kept the mic open because of wind noise. I'm thinking it
might work if I installed a PTT in the front cockpit and we talked but
broadcast the conversation, but I dont want that.
Dick N.
Message 48
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: ribs and ailerons |
Bill,
If you are going to blast me for what I am going to do maybe I should consider
dropping off the list.
Ben in MN
----- Original Message ----
From: Bill Church <eng@canadianrogers.com>
Sent: Tuesday, August 5, 2008 5:53:25 PM
Subject: RE: Pietenpol-List: ribs and ailerons
Ben, Ben, Ben.
Yes, it is possible to build an Air Camper from the Flying and Glider Manual
drawings. I wouldn't want to, but it's been done. Those drawings are so
small I find them pretty hard to read, though. Nonetheless, those are your
plans. I assume you "splurged" for the $8 for the EAA reprint of the FGM.
Use those plans to deternmine how many ribs are affected by the ailerons.
As for $150 being too much to spend, how do you plan to build the rest of
the plane if $150 for a set of plans is too much money? How are you going to
come up with the cash for a motor? How about a propellor? Wheels?
Instruments? The cheapest recent build that I can recall hearing about was
around $5,000. Assuming someone gave you all of the materials to build the
plane, and you live on a property big enough to have your own runway, what
are you going to do when it comes time to fill the tank at $5 a gallon (or
more)? The Pietenpol is one of the most economical "real" aircraft you can
build. It can be built cheaply, but it still ain't free.
Building an airplane from plans drawn in 1934 is a challenge.
Building an airplane without using those plans, and not spending any money
is called dreaming.
Pleasant dreams, Ben.
BC
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 6:30 PM
Subject: Re: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
nope. Dad said the flyer and glider manual is what to use.
you have 150 to spend??? I don't!
----- Original Message ----
From: Bill Church <eng@canadianrogers.com>
Sent: Tuesday, August 5, 2008 4:39:04 PM
Subject: RE: Pietenpol-List: ribs and ailerons
--> <eng@canadianrogers.com>
Yikes!
Ben, what are you doing trying to build a plane without having or reading
the plans???
The plans is all there is.
There ain't no other way to do it.
Maybe it's time to order a new set of plans (or put the project to rest).
Or are you just pulling our collective leg?
Bill C.
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 5:08 PM
Subject: Re: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
not sure where the rest of the plans went to though. I have hard time
reading plans though to be honest.
----- Original Message ----
From: "Phillips, Jack" <Jack.Phillips@cardinalhealth.com>
Sent: Tuesday, August 5, 2008 12:03:57 PM
Subject: RE: Pietenpol-List: ribs and ailerons
--> <Jack.Phillips@cardinalhealth.com>
Count them. You do have the plans, don't you?
Jack Phillips
NX899JP
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Ben Ramler
Sent: Tuesday, August 05, 2008 12:21 PM
Subject: Pietenpol-List: ribs and ailerons
--> <ben_ramler2002@yahoo.com>
Afternoon Group,
Here's a question... Once all 31 ribs are made how many of the ribs need
to be set aside for the ailerons?
73,
Ben in MN
Message 49
| INDEX | Back to Main INDEX |
| PREVIOUS | Skip to PREVIOUS Message |
| NEXT | Skip to NEXT Message |
| LIST | Reply to LIST Regarding this Message |
| SENDER | Reply to SENDER Regarding this Message |
|
| Subject: | Re: Ribs and sanding |
End grain cannot be succesfully glued. It may hold for a
short time with little stress on it but you'd better not trust
your backside to it. Glueing edge or flat grain will hold
up to the strength of the fibers.
Sanded joints will never be as strong as planed or scraped
ones. Wood faces should also be fresh at the time of
glueing. The best way is to learn how to use and properly
sharpen cabinet scrapers. It's not that hard but does have
it's own learning curve. Isn't that what we're supposed to
be doing? Learning?
http://woodgears.ca/scraper/index.html
http://www.taunton.com/finewoodworking/pages/w00007.asp?
"Life is change. Growth is optional. Choose wisely." ~Karen Kaiser Clark
Clif
>
> Gary's comments refer more to glue joints for end-grain spruce (or
> whatever softwood you are building with). When spruce is sawn, the end
> grain has open pores which will absorb the adhesive. If the end is sanded
> (and especially if the wood gets burned in sanding), the pores tend to get
> clogged, which impedes the absorption of the adhesive. If the epoxy
> doesn't "bite" into the wood, the joint will not achieve the strength that
> is needed. That is a bad thing.
> Bill C.
Other Matronics Email List Services
These Email List Services are sponsored solely by Matronics and through the generous Contributions of its members.
-- Please support this service by making your Contribution today! --
|
