Message 1
INDEX | Back to Main INDEX |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Another Cable Question |
Jim,
I don't remember that reference in the book. I used three for my tail
cables. I have seen some with one but wonder if the tool has a wider
surface. See pictures.
Jack
DSM
http://textors.com/DSCN4200_800x600.jpg
http://textors.com/DSCN4199_800x600.jpg
http://textors.com/DSCN4201_800x600.jpg
http://textors.com/DSCN4202_800x600.jpg
_____
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Jim Boyer
Sent: Thursday, June 16, 2011 11:01 AM
Subject: Pietenpol-List: Another Cable Question
Another cable question; in Bingelis books and in AC43 it says that 3/32
copper oval cable sleeves only need to be crimped once. I am using 3/32
cable for the tail brace cables and I know I have seen other Piets with 3/32
tail brace cables but don't remember ever seeing just one crimp on the
copper sleeve.
Is that what those of you using 3/32 cable are doing just one crimp? Tried
doing three last night as a test and it can be done but doesn't look well
and just one crimp makes the ends swell up like you stepped in the middle of
a balloon.
Cheers,
Jim B.
Message 2
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Avon tires and Johnson Airspeed indicator |
I bought a very nicely made "kit" form Kerri Ann Price a while back. Here's
the last email I have keriannprice@hotmail.com
Those Avon tires will work fine. Also ck out Avon "Speedmaster"s, very
vintage as well. I've seen these tires on Piets, so know they work.
Douwe
Message 3
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Building my first wing rib - the journey begins |
I am starting my first wing rib, and came across the following website-
http://www.2wings.com/m12/faq/wingfaq.htm#04/19/01%20RIB%20CONSTRUCTION,%20GUSSETS,%20GLUE,%20EPOXY,%20STAPLER,%20CLAMP,%20JOINT,%20CLAMPING%20SPAR%20CRUSH%20PLATE
This website is, apparently, is a Builder's area for Pitts Model 12 aircraft. In
reading through I found interesting tidbits of information, but the following
thread really caught my attention. I have cut and pasted it here to make it
easier to read-
"I re-read Cory's post, It does sound as though Cory is gluing the sticks together,
then adding gussets to each side. This would indicate that the sticks are
custom miter fitted on each end, then glued. This is NOT required on any gussetted
aircraft rib. (emphasis mine) The size of the gusset is engineered to
have adequate shear glue strength to transfer the loads and more. I recommend
that the sticks be cut as long as you can to fit the location with 90 deg cuts
on the ends such that one corner of the end of the stick contacts the adjacent
one. Factory Pitts, Stearman and Staggerwing ribs have no inter-stick contact
in places relying on the gussets only. Just like the roof over your head.
This can save bunch of build time. Ribs built in this manner are still stronger
than the required loads." (emphasis mine)
I have three questions-
1. Really? Are 90 cuts on the ends of the braces sufficient over mitered ends?
If that were true, it sure would save me time, but I also know that the Internet
is full of really bad ideas parading as "expert advice". FWIW, I have built
and glued my first rib with the vertical braces mitered to probably within 1/16th.
Am I in overkill, or doing what is the right way to construct?
2. I am thinking about building my wing ribs using Semi-Circle and Quarter-Circle
gussets (I just like the look, although, once built and covered, I won't see
them again). Since they are not the original plans type of gusset, what size
circle did some of you use for your gussets?
3. I heard the instructor in an EAA workshop I attended ask the question, "Are
you building a Timex, or a Rolex?" The point I felt he was making is that you
can build and spend thousands of extra hours fitting tolerences that don't really
make your aircraft any stronger, or you can build it using good practices
and it will be just fine. That is not the same as "The Fisherman" school of aircraft
construction, but yet it is a far cry from building a fine Swiss watch
either. I guess that I am asking for words of advice in this regard as I begin
building. Comments are appreciated.
Thanks to everyone in advance for their advice. I count today in my Builder's Log
as the day I began building my Pietenpol. Everything up until now has been
"research", and I don't think the FAA or anyone else gives two hoots about how
many hours of research I did. They are more interested in what I built, how I
built it, and (at least to me) how many hours I spent building.
--------
Semper Fi,
Terry
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343267#343267
Message 4
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Avon tires and Johnson Airspeed indicator |
I have Avon Speedmasters on mine and have been very pleased with them.
Jack Phillips
NX899JP "Icarus Plummet"
Smith Mountain Lake, Virginia
_____
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Douwe
Blumberg
Sent: Friday, June 17, 2011 8:13 AM
Subject: Pietenpol-List: Avon tires and Johnson Airspeed indicator
I bought a very nicely made "kit" form Kerri Ann Price a while back. Here's
the last email I have keriannprice@hotmail.com
Those Avon tires will work fine. Also ck out Avon "Speedmaster"s, very
vintage as well. I've seen these tires on Piets, so know they work.
Douwe
Message 5
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
90 degree cuts are fine. I compromised and angled mine to give me a little more
suface area to glue.
--------
John
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343270#343270
Message 6
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Another Cable Question |
Jack, I ordered both ferrules swaging tool from ACS. The ferrules are
3/8-in long and the swager is 1/2-inch wide so the swage is done in just
one crimp. I think the 1 vs 2 vs 3 crimps have reference to the
crimping tool that has a much more narrow 'bite'. I think you are using
much longer ferrules (copper colored vs plated) and a more narrow
crimping tool.
----- Original Message -----
From: Jack
To: pietenpol-list@matronics.com
Sent: Friday, June 17, 2011 6:33 AM
Subject: RE: Pietenpol-List: Another Cable Question
Jim,
I don't remember that reference in the book. I used three for my tail
cables. I have seen some with one but wonder if the tool has a wider
surface. See pictures.
Jack
DSM
http://textors.com/DSCN4200_800x600.jpg
http://textors.com/DSCN4199_800x600.jpg
http://textors.com/DSCN4201_800x600.jpg
http://textors.com/DSCN4202_800x600.jpg
-------------------------------------------------------------------------
-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Jim
Boyer
Sent: Thursday, June 16, 2011 11:01 AM
To: pietenpol-list
Subject: Pietenpol-List: Another Cable Question
Another cable question; in Bingelis books and in AC43 it says that
3/32 copper oval cable sleeves only need to be crimped once. I am using
3/32 cable for the tail brace cables and I know I have seen other Piets
with 3/32 tail brace cables but don't remember ever seeing just one
crimp on the copper sleeve.
Is that what those of you using 3/32 cable are doing just one crimp?
Tried doing three last night as a test and it can be done but doesn't
look well and just one crimp makes the ends swell up like you stepped in
the middle of a balloon.
Cheers,
Jim B.
http://www.matronics.com/Navigator?Pietenpol-Listhttp://forums.matronics.
comhttp://www.matronics.com/contribution
Message 7
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Another Cable Question |
#2. I meant to attach a pic to the first post so if I can get it to
come up here it is.
----- Original Message -----
From: Jack
To: pietenpol-list@matronics.com
Sent: Friday, June 17, 2011 6:33 AM
Subject: RE: Pietenpol-List: Another Cable Question
Jim,
I don't remember that reference in the book. I used three for my tail
cables. I have seen some with one but wonder if the tool has a wider
surface. See pictures.
Jack
DSM
http://textors.com/DSCN4200_800x600.jpg
http://textors.com/DSCN4199_800x600.jpg
http://textors.com/DSCN4201_800x600.jpg
http://textors.com/DSCN4202_800x600.jpg
-------------------------------------------------------------------------
-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Jim
Boyer
Sent: Thursday, June 16, 2011 11:01 AM
To: pietenpol-list
Subject: Pietenpol-List: Another Cable Question
Another cable question; in Bingelis books and in AC43 it says that
3/32 copper oval cable sleeves only need to be crimped once. I am using
3/32 cable for the tail brace cables and I know I have seen other Piets
with 3/32 tail brace cables but don't remember ever seeing just one
crimp on the copper sleeve.
Is that what those of you using 3/32 cable are doing just one crimp?
Tried doing three last night as a test and it can be done but doesn't
look well and just one crimp makes the ends swell up like you stepped in
the middle of a balloon.
Cheers,
Jim B.
http://www.matronics.com/Navigator?Pietenpol-Listhttp://forums.matronics.
comhttp://www.matronics.com/contribution
Message 8
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Congratulations on your first wing rib, Terry. Like John, I miter the intercoastals
but I've also read that the 90s are fine. As always, the engineers, A&Ps
and IAs can correct as they see fit - that's my standard disclaimer since I
routinely say dumb things.
I like the "timex vs. rolex" analogy. Unfortunately, it's hard to know what right
looks like when you're starting. That's why you develop your list of trusted
people on this site and seek their advice. You also have your local technical
counselors.
Lemme see: "timex vs. rolex," "pole-vaulting over mouse turds," and, "it ain't
the space shuttle." Not excuses to do sloppy work, but encouragement to do airworthy
work and make progress.
--------
Kevin "Axel" Purtee
NX899KP
Austin/Georgetown, TX
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343275#343275
Message 9
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Take a look at the Help for Home Builders section of EAA.org. There are a number
of videos there building a wood wing. All of them cut angles. I believe you
will find most of the folks here also cut angles.
Another advantage to cutting the angles, is you can remove the rib from the jig
without first attaching one side of the gussets. This allowed me to always have
a rib in the jig and two others at the "gusset station". Cleaner and neater.
This also allows you smooth the joints out of the jig, which is much easier.
You can check out my blog at: http://pietenpol-989cb.blogspot.com
On the gussets themselves, I went with the rectangle. I ended up with 4 different
sizes, but the mass majority of them are 1.5" x 1.0". The other sizes were
1.25" x 1.0" - only two of these per side. The other two sizes were specific for
the nose and the tail. Trimmed on the router table. Video on the blog.
Good luck and enjoy the time. If time is real important to save, your going to
be in trouble.
Chuck
989CB
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343276#343276
Message 10
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Didn't really answer a couple of your questions - standard disclaimer still applies:
Do as good as you can on the woodwork. I try for 1/32" tolerances. For gusseted
joints I'll go to 1/16". This obviously does not apply if you cut 90 degree
angles on your rib intercoastals.
Ask Gene Rambo about the size of the round gussets on the ribs. TLAR tells me
that 1.25" radius would be ok.
--------
Kevin "Axel" Purtee
NX899KP
Austin/Georgetown, TX
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343278#343278
Message 11
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Another Cable Question |
That's what I use.1 crimp.
Gary
Do not archive
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Charles
Campbell
Sent: Friday, June 17, 2011 6:24 AM
Subject: Re: Pietenpol-List: Another Cable Question
#2. I meant to attach a pic to the first post so if I can get it to come up
here it is.
----- Original Message -----
From: Jack <mailto:jack@textors.com>
Sent: Friday, June 17, 2011 6:33 AM
Subject: RE: Pietenpol-List: Another Cable Question
Jim,
I don't remember that reference in the book. I used three for my tail
cables. I have seen some with one but wonder if the tool has a wider
surface. See pictures.
Jack
DSM
http://textors.com/DSCN4200_800x600.jpg
http://textors.com/DSCN4199_800x600.jpg
http://textors.com/DSCN4201_800x600.jpg
http://textors.com/DSCN4202_800x600.jpg
_____
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Jim Boyer
Sent: Thursday, June 16, 2011 11:01 AM
Subject: Pietenpol-List: Another Cable Question
Another cable question; in Bingelis books and in AC43 it says that 3/32
copper oval cable sleeves only need to be crimped once. I am using 3/32
cable for the tail brace cables and I know I have seen other Piets with 3/32
tail brace cables but don't remember ever seeing just one crimp on the
copper sleeve.
Is that what those of you using 3/32 cable are doing just one crimp? Tried
doing three last night as a test and it can be done but doesn't look well
and just one crimp makes the ends swell up like you stepped in the middle of
a balloon.
Cheers,
Jim B.
http://www.matronics.com/Navigator?Pietenpol-List
http://forums.matronics.com
http://www.matronics.com/contribution
href="http://www.matronics.com/Navigator?Pietenpol-List">http://www.matronic
s.com/Navigator?Pietenpol-List
href="http://forums.matronics.com">http://forums.matronics.com
href="http://www.matronics.com/contribution">http://www.matronics.com/c
Message 12
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Thanks for everyone's input. Chuck, thanks for the advice about time. Flying is
my job, so staying proficient is not a factor. I look at this as a journey, as
I said. If the destination is the only goal, you will miss the joy of the journey.
I am in no rush.
I also saw the three step wing rib process on the westcoastpiet. com website. I
like the ability to remove the rib from the jig and apply the gussets without
staples or nails. So for that reason alone I think that I will stay with the
mitered braces. I think that I will also stick with the rectangle gussets- easier
to cut, and much less waste.
I will send pictures as I get a little further on the trip! Thanks again to all.
--------
Semper Fi,
Terry
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343282#343282
Message 13
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Terry,
I questioned the rib joints myself but found comfort in a bridge I passed over
a few days later. I knew I was going that way again this morning so took some
pictures for you. Check out their gussets.
--------
John
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343285#343285
Attachments:
http://forums.matronics.com//files/bridge2_854.jpg
http://forums.matronics.com//files/bridge1_170.jpg
Message 14
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: [eaa1114-discuss] Letter from Capt. Ray Fowler,Chief |
Pilot f
Extremely well said...thanks for forwarding! A very sad loss of a piece of history,
but thankfully not infinitely compounded by loss of life or injury.
--------
--Randall
02xB || !02xB
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343286#343286
Message 15
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Great picture, John. Definitely worth a thousand words. Or a couple of beverages
at Brodhead - my treat.
--------
Semper Fi,
Terry
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343291#343291
Message 16
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
I used a 2" hole saw for my gussets. Then used an old school paper cutter t
o cut those gussets in 1/2 and 1/4 pieces.- I believe I have pictures on
my website.
Michael Perez
Karetaker Aero
www.karetakeraero.com
Message 17
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Since it hasn't been mentioned yet, I'll do it now:
Refer to the Bingelis books. They will provide answers to all of your questions.
Attached is a Tony Bingelis sketch showing various joint conditions, all deemed
to be acceptable. If you don't own the set of Bingelis books, get one. If
you have a set, read them. Such a wealth of homebuilt aircraft information.
So, in response to your questions:
1. Yes, 90degree cuts on the ends of the braces are sufficient. They will be slightly
less strong than mitered (less bonding area), but not significantly. Personally,
I prefer mitered joints, but I enjoy woodworking, and take pride in
nice fitting joints, whether anyone else knows about them or not - but that's
just me. I'm not sure what you mean by your statement that your braces have been
"mitered to probably within 1/16th". Do you mean you have 1/16" gaps between
the sticks? Basically the sticks should butt against the top and bottom capstrips.I
would avoid gaps. A disc sander is an invaluable tool in building ribs
(and many other parts) . I use mine ALL the time. Probably less than $100. Get
the biggest size you can find. Mine is 8 inch diameter.
2. I used circular gussets - just liked the look better (but that's me). I made
mine 2" diameter, and cut them into halves and quarters with a thin blade (scroll
saw).
3. Build the way you want to build, and are capable of. Some homebuilt aircraft
have woodwork that looks like fine furniture, and some have woodwork that...
doesn't. Strength will rely on proper techniques, and making sure that glue joints
have proper contact (no gaps between wood pieces that are not filled with
the proper amount of glue). How your aircraft performs will depend largely on
the symmetry and squareness (wherever things are supposed to be square) of your
construction, not how pretty it looks. Always remember "Keep it light". Personally,
I think I'm aiming for a Seiko. A little nicer than a Timex, but much
more reasonably priced than a Rolex.
Lastly, I don't think that the FAA gives a hoot about how many hours you spent
building your plane (unless someone else did more hours on your plane than you
did). What they will care about is whether or not YOU built it.
One rib down, and a bunch more to go. Before you know it you'll have a whole wing's
worth of ribs (unless you get distracted, like another builder, whose name
rhymes with Gary Boothe).
Bill C.
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343302#343302
Attachments:
http://forums.matronics.com//files/bingelis_rib_joints_648.jpg
Message 18
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Another Cable Question |
Hi Jack,
thats what bothered me; it looked like some had one crimp but it was much wider.
It could have been just that the 3 crimps blended together.
Both AC43-13 and Bingelis books say just one for 3/32" and 3 for 1/8" sleeves.
Thanks for the pictures,
Jim B.
Message 19
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Not sure that it matters much, but I mitered (sanded) each diagonal and upright
to fit precisely and I honestly don't think it took me any longer to go this
route. I didn't custom fit each part to each assembly, rather I made a set of
"master" parts as I laid out the first rib and used each of these master parts
to make the remaining parts by marking the cut angles on long pieces of capstrip.
Most of us do this anyway (mark lengths) in order to cut our parts to the
correct length, even if we are cutting 90s. So, after I marked my parts I
went to the band saw and rip, rip, rip, rip, rip. Now I've got a stack of parts
with angles marked on each end, so I take them to my disk sander and sand,
sand, sand, sand, sand them to match the markings. It actually went really quick,
and each part was fabricated to the identical dimension as the original master
part. Once I had all these built, which only took me a few work sessions,
I had an entire assembly line set up. Making these parts in batches is a LOT
quicker than making them as you go (marking each piece, walking to the saw
each time, etc.).
I still have all these master parts. They fit perfectly in my jig in the event
that I need to make a repair, or build another Piet later on.
I know that all this isn't necessary, but I just wanted to share the way I did
mine. I would argue that their is some degree of added strength in the increased
contact area. I used the same process with my fuse halves... all the diagonals
and uprights were sanded to match. The fit is snug and leaves no voids.
I think this serves to not only provide more surface area, but also better alignment...
especially when doing a number of the same assemblies, such as ribs.
My $.02
Some of the diagonals cut and sorted.
Gussets ready to go.
--------
Mark Chouinard
Wings, Center Section and Empannage framed up - Working on Fuselage
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343308#343308
Message 20
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Wow! Bill nailed it. We must have been writing at the same time.
I'll agree... the disc sander is an excellent tool. I got mine (6" with 4" belt)
for $100. You can probably do much better than I did by scouring Craigslist.
One more thing I want to agree with... I too enjoy woodworking and take pride in
nicely fitting joints. Not to brag, but I had a 20+ year wood shop instructor
and airplane builder come into my hangar the other night (he has 6 airplanes).
I noticed him looking over my project while I talked to another guy. Later
on I asked him what he thought and he said, "you are doing excellent work".
Yep, I'm glad I've taken a little extra time (emphasis on little) to do my best
work. Is it THE best work? Probably not, but I'm trying.
--------
Mark Chouinard
Wings, Center Section and Empannage framed up - Working on Fuselage
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343311#343311
Message 21
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
...not that there's anything wrong with getting distracted, but, if I had it
to do over again, I'd take my A.D.D. medication and stick with completing
the ribs in one shot!
Gary
Do not archive
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Bill Church
Sent: Friday, June 17, 2011 9:19 AM
Subject: Pietenpol-List: Re: Building my first wing rib - the journey begins
Since it hasn't been mentioned yet, I'll do it now:
Refer to the Bingelis books. They will provide answers to all of your
questions. Attached is a Tony Bingelis sketch showing various joint
conditions, all deemed to be acceptable. If you don't own the set of
Bingelis books, get one. If you have a set, read them. Such a wealth of
homebuilt aircraft information.
So, in response to your questions:
1. Yes, 90degree cuts on the ends of the braces are sufficient. They will be
slightly less strong than mitered (less bonding area), but not
significantly. Personally, I prefer mitered joints, but I enjoy woodworking,
and take pride in nice fitting joints, whether anyone else knows about them
or not - but that's just me. I'm not sure what you mean by your statement
that your braces have been "mitered to probably within 1/16th". Do you mean
you have 1/16" gaps between the sticks? Basically the sticks should butt
against the top and bottom capstrips.I would avoid gaps. A disc sander is an
invaluable tool in building ribs (and many other parts) . I use mine ALL the
time. Probably less than $100. Get the biggest size you can find. Mine is 8
inch diameter.
2. I used circular gussets - just liked the look better (but that's me). I
made mine 2" diameter, and cut them into halves and quarters with a thin
blade (scroll saw).
3. Build the way you want to build, and are capable of. Some homebuilt
aircraft have woodwork that looks like fine furniture, and some have
woodwork that... doesn't. Strength will rely on proper techniques, and
making sure that glue joints have proper contact (no gaps between wood
pieces that are not filled with the proper amount of glue). How your
aircraft performs will depend largely on the symmetry and squareness
(wherever things are supposed to be square) of your construction, not how
pretty it looks. Always remember "Keep it light". Personally, I think I'm
aiming for a Seiko. A little nicer than a Timex, but much more reasonably
priced than a Rolex.
Lastly, I don't think that the FAA gives a hoot about how many hours you
spent building your plane (unless someone else did more hours on your plane
than you did). What they will care about is whether or not YOU built it.
One rib down, and a bunch more to go. Before you know it you'll have a whole
wing's worth of ribs (unless you get distracted, like another builder, whose
name rhymes with Gary Boothe).
Bill C.
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343302#343302
Attachments:
http://forums.matronics.com//files/bingelis_rib_joints_648.jpg
Message 22
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
What I meant about time is that, you are right that the FAA doesn't care how many
hours I put into the airplane, as long as it is done right. I only meant a
tally of hours would be meaningful to me.
I appreciate all of the photos as it helps me as I go to get ideas.
I think that the Seiko comparison may be the best goal - not to low end, not too
high end, but built well and built to last.
I do have the Bingelis books, but, frankly, I do not remember that diagram of the
braces and gussets. Maybe it is a different edition. If you can tell me the
book and page, I will go back and search for it.
Back to work.
--------
Semper Fi,
Terry
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343315#343315
Message 23
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Terry,
All it takes is a couple pictures of some bridges? Hang on, mate...got
several bridges near where I live...
Gary
Do not archive
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of
jarheadpilot82
Sent: Friday, June 17, 2011 7:48 AM
Subject: Pietenpol-List: Re: Building my first wing rib - the journey begins
<jarheadpilot82@hotmail.com>
Great picture, John. Definitely worth a thousand words. Or a couple of
beverages at Brodhead - my treat.
--------
Semper Fi,
Terry
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343291#343291
Message 24
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Terry,
I mitred my rib spacers and cut square/rectangular gussets. Do what Mark did and
cut multiple spacers and gussets. It's really nice to be able to make a rib
a day without having to stop and cut individual pieces.
Building the ribs was great--starting on the project and seeing progress each day.
Every part of it was exciting.
Tom
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343320#343320
Attachments:
http://forums.matronics.com//files/rib_945.jpg
http://forums.matronics.com//files/rib_gusset_166.jpg
Message 25
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
I mitered my rib pieces. If you make them like an assembly line it
doesn't take all that long if you have a power sander. I ended up with
all the individual rib pieces numbered and rubber banded together on my
workbench, so putting together a rib didn't take all that long, maybe an
hour to glue and nail one side. In the long run it doesn't cost much
more to build a Rolex. Its your time, so its up to you. I don't regret
it myself.
Ben Charvet
Titusville, Fl
On 6/17/2011 8:17 AM, jarheadpilot82 wrote:
> --> Pietenpol-List message posted by: "jarheadpilot82"<jarheadpilot82@hotmail.com>
>
> I am starting my first wing rib, and came across the following website-
>
> http://www.2wings.com/m12/faq/wingfaq.htm#04/19/01%20RIB%20CONSTRUCTION,%20GUSSETS,%20GLUE,%20EPOXY,%20STAPLER,%20CLAMP,%20JOINT,%20CLAMPING%20SPAR%20CRUSH%20PLATE
>
> This website is, apparently, is a Builder's area for Pitts Model 12 aircraft.
In reading through I found interesting tidbits of information, but the following
thread really caught my attention. I have cut and pasted it here to make it
easier to read-
>
> "I re-read Cory's post, It does sound as though Cory is gluing the sticks together,
then adding gussets to each side. This would indicate that the sticks
are custom miter fitted on each end, then glued. This is NOT required on any gussetted
aircraft rib. (emphasis mine) The size of the gusset is engineered to
have adequate shear glue strength to transfer the loads and more. I recommend
that the sticks be cut as long as you can to fit the location with 90 deg cuts
on the ends such that one corner of the end of the stick contacts the adjacent
one. Factory Pitts, Stearman and Staggerwing ribs have no inter-stick contact
in places relying on the gussets only. Just like the roof over your head.
This can save bunch of build time. Ribs built in this manner are still stronger
than the required loads." (emphasis mine)
>
> I have three questions-
>
> 1. Really? Are 90 cuts on the ends of the braces sufficient over mitered ends?
If that were true, it sure would save me time, but I also know that the Internet
is full of really bad ideas parading as "expert advice". FWIW, I have built
and glued my first rib with the vertical braces mitered to probably within
1/16th. Am I in overkill, or doing what is the right way to construct?
>
> 2. I am thinking about building my wing ribs using Semi-Circle and Quarter-Circle
gussets (I just like the look, although, once built and covered, I won't
see them again). Since they are not the original plans type of gusset, what size
circle did some of you use for your gussets?
>
> 3. I heard the instructor in an EAA workshop I attended ask the question, "Are
you building a Timex, or a Rolex?" The point I felt he was making is that you
can build and spend thousands of extra hours fitting tolerences that don't really
make your aircraft any stronger, or you can build it using good practices
and it will be just fine. That is not the same as "The Fisherman" school of
aircraft construction, but yet it is a far cry from building a fine Swiss watch
either. I guess that I am asking for words of advice in this regard as I begin
building. Comments are appreciated.
>
> Thanks to everyone in advance for their advice. I count today in my Builder's
Log as the day I began building my Pietenpol. Everything up until now has been
"research", and I don't think the FAA or anyone else gives two hoots about how
many hours of research I did. They are more interested in what I built, how
I built it, and (at least to me) how many hours I spent building.
>
> --------
> Semper Fi,
>
> Terry
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=343267#343267
>
>
--
Ben Charvet, PharmD
Staff Pharmacist
Parrish Medical center
Message 26
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Gary,
I don't want to buy a bridge, I just like the visual... ;o)
--------
Semper Fi,
Terry
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343325#343325
Message 27
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Ben:
Thats how I did my rib pieces and like you it took about 1 hour per rib to
assemble. After assembling one rib, I took the staples out of the one I did
the day before. I think on my best day one Saturday, I actually did 3 ribs.
Rick Schreiber,
Valparaiso In
> [Original Message]
> From: Ben Charvet <bencharvet@gmail.com>
> To: <pietenpol-list@matronics.com>
> Date: 6/17/2011 1:32:44 PM
> Subject: Re: Pietenpol-List: Building my first wing rib - the journey
begins
>
> I mitered my rib pieces. If you make them like an assembly line it
> doesn't take all that long if you have a power sander. I ended up with
> all the individual rib pieces numbered and rubber banded together on my
> workbench, so putting together a rib didn't take all that long, maybe an
> hour to glue and nail one side. In the long run it doesn't cost much
> more to build a Rolex. Its your time, so its up to you. I don't regret
> it myself.
>
> Ben Charvet
> Titusville, Fl
> On 6/17/2011 8:17 AM, jarheadpilot82 wrote:
> > --> Pietenpol-List message posted by:
"jarheadpilot82"<jarheadpilot82@hotmail.com>
> >
> > I am starting my first wing rib, and came across the following website-
> >
> >
http://www.2wings.com/m12/faq/wingfaq.htm#04/19/01%20RIB%20CONSTRUCTION,%20G
USSETS,%20GLUE,%20EPOXY,%20STAPLER,%20CLAMP,%20JOINT,%20CLAMPING%20SPAR%20CR
USH%20PLATE
> >
> > This website is, apparently, is a Builder's area for Pitts Model 12
aircraft. In reading through I found interesting tidbits of information,
but the following thread really caught my attention. I have cut and pasted
it here to make it easier to read-
> >
> > "I re-read Cory's post, It does sound as though Cory is gluing the
sticks together, then adding gussets to each side. This would indicate
that the sticks are custom miter fitted on each end, then glued. This is
NOT required on any gussetted aircraft rib. (emphasis mine) The size of
the gusset is engineered to have adequate shear glue strength to transfer
the loads and more. I recommend that the sticks be cut as long as you can
to fit the location with 90 deg cuts on the ends such that one corner of
the end of the stick contacts the adjacent one. Factory Pitts, Stearman and
Staggerwing ribs have no inter-stick contact in places relying on the
gussets only. Just like the roof over your head. This can save bunch of
build time. Ribs built in this manner are still stronger than the required
loads." (emphasis mine)
> >
> > I have three questions-
> >
> > 1. Really? Are 90 cuts on the ends of the braces sufficient over
mitered ends? If that were true, it sure would save me time, but I also
know that the Internet is full of really bad ideas parading as "expert
advice". FWIW, I have built and glued my first rib with the vertical braces
mitered to probably within 1/16th. Am I in overkill, or doing what is the
right way to construct?
> >
> > 2. I am thinking about building my wing ribs using Semi-Circle and
Quarter-Circle gussets (I just like the look, although, once built and
covered, I won't see them again). Since they are not the original plans
type of gusset, what size circle did some of you use for your gussets?
> >
> > 3. I heard the instructor in an EAA workshop I attended ask the
question, "Are you building a Timex, or a Rolex?" The point I felt he was
making is that you can build and spend thousands of extra hours fitting
tolerences that don't really make your aircraft any stronger, or you can
build it using good practices and it will be just fine. That is not the
same as "The Fisherman" school of aircraft construction, but yet it is a
far cry from building a fine Swiss watch either. I guess that I am asking
for words of advice in this regard as I begin building. Comments are
appreciated.
> >
> > Thanks to everyone in advance for their advice. I count today in my
Builder's Log as the day I began building my Pietenpol. Everything up until
now has been "research", and I don't think the FAA or anyone else gives two
hoots about how many hours of research I did. They are more interested in
what I built, how I built it, and (at least to me) how many hours I spent
building.
> >
> > --------
> > Semper Fi,
> >
> > Terry
> >
> >
> >
> >
> > Read this topic online here:
> >
> > http://forums.matronics.com/viewtopic.php?p=343267#343267
> >
> >
> >
> >
> >
> >
> >
> >
> >
> >
> >
>
>
> --
> Ben Charvet, PharmD
> Staff Pharmacist
> Parrish Medical center
>
Message 28
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Got a head for my engine this week... aluminum Thomas head 7:1... and made a
decision on the ignition.
got a mallory distributor and will run dual points like the corvair guys.. i've
been driving my '30 AA a lot lately and even the original ignition it that old
truck just works. no fabbing a mount and drive for the magneto... short wire
runs.. and easy maintenance... i'm digging it.
http://s1125.photobucket.com/albums/l593/jfaithbass/
got some photos up
jeff
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343339#343339
Message 29
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Very nice looking work, Jeff! Are you coming to Brodhead this year?
Jack Phillips
NX899JP "Icarus Plummet"
Smith Mountain Lake, Virginia
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of bender
Sent: Friday, June 17, 2011 5:53 PM
Subject: Pietenpol-List: A engine
Got a head for my engine this week... aluminum Thomas head 7:1... and made
a decision on the ignition.
got a mallory distributor and will run dual points like the corvair guys..
i've been driving my '30 AA a lot lately and even the original ignition it
that old truck just works. no fabbing a mount and drive for the magneto...
short wire runs.. and easy maintenance... i'm digging it.
http://s1125.photobucket.com/albums/l593/jfaithbass/
got some photos up
jeff
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343339#343339
Message 30
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Who's the guy with all the dark hair, Ben?
;)
do not archive
--------
Kevin "Axel" Purtee
NX899KP
Austin/Georgetown, TX
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343346#343346
Message 31
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
thanks
what is the date ??
i thought about riding a bike up... sold my 120
wish the piet was done ... but soon enough
jeff
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343350#343350
Message 32
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
And so much of it....Just to remind you guys just getting started, this
process is a journey, and a lot of life goes on in the background.
Ben
On 6/17/2011 6:53 PM, kevinpurtee wrote:
> --> Pietenpol-List message posted by: "kevinpurtee"<kevin.purtee@us.army.mil>
>
> Who's the guy with all the dark hair, Ben?
>
> ;)
>
> do not archive
>
> --------
> Kevin"Axel" Purtee
> NX899KP
> Austin/Georgetown, TX
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=343346#343346
>
>
--
Ben Charvet, PharmD
Staff Pharmacist
Parrish Medical center
Message 33
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Dates for Brodhead are Thursday 7/21 thru Saturday 7/23. On Sunday
everybody either goes home or goes to Oshkosh.
Jack Phillips
NX899JP "Icarus Plummet"
Smith Mountain Lake, Virginia
-----Original Message-----
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of bender
Sent: Friday, June 17, 2011 7:17 PM
Subject: Pietenpol-List: Re: A engine
thanks
what is the date ??
i thought about riding a bike up... sold my 120
wish the piet was done ... but soon enough
jeff
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343350#343350
Message 34
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Building my first wing rib - the journey begins |
Yeah, you can see all 16 years in my progress pics.
do not archive
--------
Kevin "Axel" Purtee
NX899KP
Austin/Georgetown, TX
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=343362#343362
Other Matronics Email List Services
These Email List Services are sponsored solely by Matronics and through the generous Contributions of its members.
-- Please support this service by making your Contribution today! --
|
