Today's Message Index:
----------------------
0. 12:19 AM - What's Your Contribution Used For? (Matt Dralle)
1. 04:11 AM - Corvair College $21 (Chuck Campbell)
2. 04:15 AM - Previous E-mail (Chuck Campbell)
3. 05:05 AM - (Douwe Blumberg)
4. 07:08 AM - Re: No Title (Don Emch)
5. 07:46 AM - Re: Corvair College $21 (K5YAC)
6. 08:03 AM - Re: Wing rib question (johnnysdrop)
7. 08:34 AM - Re: (Dortch, Steven D MAJ NG NG FORSCOM)
8. 08:37 AM - Re: Re: Corvair College $21 (Chuck Campbell)
9. 08:48 AM - Re: Wing rib question (TOM STINEMETZE)
10. 09:21 AM - Re: Wing rib question (Chuck Campbell)
11. 10:10 AM - Re: Vet's day (Chuck Campbell)
12. 10:43 AM - Wing height above fuselage (j_dunavin)
13. 11:37 AM - Re: Wing height above fuselage (helspersew@aol.com)
14. 12:13 PM - Re: Wing height above fuselage (Jim Boyer)
15. 02:23 PM - Re: New to List (Bill Church)
16. 03:17 PM - Re: New to List (K5YAC)
17. 05:16 PM - Re: Vet's day (Jack)
18. 06:56 PM - Re: New to List (Bryan Reed)
19. 07:06 PM - Re: Wing height above fuselage (Steve Emo)
20. 09:17 PM - Re: Wing height above fuselage (AMsafetyC@aol.com)
Message 0
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | What's Your Contribution Used For? |
Dear Listers,
You might have wondered at some pointd, "What's my Contribution used for?" Here
are just a few examples of what your direct List support enables... It provides
for the expensive, commercial-grade Internet connection used on the List.
It pays for the regular system hardware and software upgrades enabling the highest
performance possible for List services such as the Archive Search Engine,
List Browser, and the Web Forums. It pays for over 21 years (yeah, I really
said *21* years) worth of on line archive data available for instant search
and access. And, it offsets the many hours spent writing, developing, and maintaining
the custom applications that power this List Service such as the List
Browse, Search Engine, Forums, and Wiki.
But most importantly, your List Contribution enables a forum where you and your
peers can communicate freely in an environment that is free from moderation,
censorship, advertising, commercialism, SPAM, and computer viruses.
It is YOUR CONTRIBUTION that directly enables these aspects of Matronics List services.
Please support it today with your List Contribution. Its one of the
best investments you can make in your Sport!
List Contribution Web Site:
http://www.matronics.com/contribution
or, you can send a personal check to the following address:
Matronics / Matt Dralle
581 Jeannie Way
Livermore, CA 94550
Thank you for your support!
Matt Dralle
Email List Administrator
Message 1
INDEX | Back to Main INDEX |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Corvair College $21 |
Just got back Sunday night from one of the most enjoyable weekends I've
ever had (excluding those I have had with my friend, my wife.) I went
down with a short block (crankshaft and cam shaft installed between two
halves of the case.) Came home with the engine in the condition shown
in the attachment. I was hoping to run the engine for the first time,
but was delayed the first two days waiting for Dan Weseman to get around
to me to correctly install the 5th bearing. Got most of the work done
on Saturday night and Sunday morning with a lot of help from John
Franklin and his friend, Ken. Wish I could have run it, but that will
just have to wait until the fuselage is far enough along to hang the
engine on it. Chuck
Message 2
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
I hit the % sign instead of the # sign in "Corvair College $21). Got a
new keyboard and I'm not used to it yet. C
Message 3
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Hey all!
I've been completely out of touch with everything for about three weeks as
I've been finishing the NYC monument and installing it. Just got back and
saw some nice comments on the forum and wanted to say thank you!, and
apologize for being tardy in responding. I just haven't been around my
computer.
It's been a wonderful opportunity and experience working with our Special
Operations community, very humbling when you begin to learn what they are
off doing for us while we are safely sleeping in our beds at night.
Main thing I'm looking forward to is getting back to the Piet!!
Thanks again!
Douwe
Message 4
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Douwe ... The monument is amazing! Very impressive! Very nice to see a good guy
like you being involved in a project like that.
Now get crackin' on that Piet! Spring is just around the corner!
Don Emch
NX899DE
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=358003#358003
Message 5
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Corvair College $21 |
Can't see the photo?
--------
Mark Chouinard
Wings, Center Section and Empannage framed up - Working on Fuselage
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=358007#358007
Message 6
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Wing rib question |
Thank you all for your replies and an interesting side topic!
I found that on my first rib the gusset didn't hold along the lower capstrip beneath
the nose block and there was spring in the capstrip.
I did sand the ply beforehand so hope that wasn't an issue, guess it was ok as
no other gusset didn't glue.
I just reglued that piece and stapled it rather than weighting down then applied
a slightly larger gusset to the reverse as I think the first was a little small
and stapled that, worked a treat then.
Also had someone with a lot of experience show me the glue process so guess that
wasn.t a problem either!
Only another 27 to make now!
John
--------
The only way is UP
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=358013#358013
Message 7
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: tenpol-List: |
Really neat statue. Great job Douwe!
My favorite photo of that campaign is a SF troop riding a mountain pony (or donkey
can't remember) and using a laptop as he rode.
Blue Skies
Steve D
----- Original Message -----
From: Douwe Blumberg <douweblumberg@earthlink.net>
Subject: Pietenpol-List:
> Hey all!
>
>
>
> I've been completely out of touch with everything for about three
> weeks as
> I've been finishing the NYC monument and installing it. Just got
> back and
> saw some nice comments on the forum and wanted to say thank you!, and
> apologize for being tardy in responding. I just haven't been
> around my
> computer.
>
>
>
> It's been a wonderful opportunity and experience working with our
> SpecialOperations community, very humbling when you begin to learn
> what they are
> off doing for us while we are safely sleeping in our beds at night.
>
>
>
> Main thing I'm looking forward to is getting back to the Piet!!
>
>
>
> Thanks again!
>
>
>
> Douwe
>
Message 8
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Corvair College $21 |
Put it in the attachment collumn. Don't know how else to do it. C
----- Original Message -----
From: "K5YAC" <hangar10@cox.net>
Sent: Tuesday, November 15, 2011 10:44 AM
Subject: Pietenpol-List: Re: Corvair College $21
>
> Can't see the photo?
>
> --------
> Mark Chouinard
> Wings, Center Section and Empannage framed up - Working on Fuselage
>
>
>
>
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=358007#358007
>
>
>
>
>
>
>
>
>
>
>
Message 9
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Wing rib question |
John:
I will assume (and I know the problems with that) that you are using T-88
for your glue. This is a very easy to use product but there is at least
one thing you need to be careful of - Stop glueing parts with the current
batch when you start to have the unused glue begin to stiffen up. The
glue has to penetrate the wood to a degree in order for the bond to be
strong. If the glue is already starting to set up it skins over and will
not penetrate. Thus your parts do not bond correctly.
If you are a cheapskate like me you tend to not want to waste any of that
precious glue so you keep using it past where it is wise to do so.
Just my $ 0.02.
Stinemetze
N328X
>>> "johnnysdrop" <johnnysdrop@googlemail.com> 11/15/2011 10:00 AM >>>
I found that on my first rib the gusset didn't hold along the lower
capstrip beneath the nose block and there was spring in the capstrip.
I did sand the ply beforehand so hope that wasn't an issue, guess it was
ok as no other gusset didn't glue.
I just reglued that piece and stapled it rather than weighting down then
applied a slightly larger gusset to the reverse as I think the first was a
little small and stapled that, worked a treat then.
Also had someone with a lot of experience show me the glue process so
guess that wasn.t a problem either!
Only another 27 to make now!
John
Message 10
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Wing rib question |
I used the GN-1 airfoil because I had a drawing of it and started building
ribs before I got the Pietenpol plans. I can't see that much difference in
them. The Piet rib looks like it is a bit more "skinny" at the nose than
the GN-1 rib. Regardless, I am stuck with what I have because both wings
are finnished. I know the GN-1 flies because I've seen pictures of one in
the air. Incidentally, I did not have to pre-bend the lower capstrip. I
did on the first couple of ribs I did and then tried one in the jig dry and
un-pre-bent and it worked fine. C
----- Original Message -----
From: "Dan Yocum" <yocum@fnal.gov>
Sent: Sunday, November 13, 2011 11:05 PM
Subject: Re: Pietenpol-List: Wing rib question
>
> Hi John,
>
> Good to hear from you - I hope you're doing well.
>
> I'm building a Piet with a GA30-612 airfoil to go along with N8031 and I
> found that I have to pre-bend the bottom capstrip to make it fit in the
> jig. Many have said this is not the case with the FC-10 airfoil.
>
> Depending on how many blocks you have (the more, the better), you may be
> able to stick it right into the jig like Greg did.
>
> Cheers!
> Dan
>
>
> On 11/13/2011 07:17 PM, John Theron wrote:
>> Has anyone had cause to pre bend the lower wing rib section forward of
>> the front spar or have pre bent it anyway?
>> John
>>
>> *
>>
>>
>> *
>
> --
> Dan Yocum
> Fermilab 630.840.6509
> yocum@fnal.gov, http://fermigrid.fnal.gov
> "I fly because it releases my mind from the tyranny of petty things."
>
>
>
Message 11
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
US Navy, 1941-1945 ; 1951-1953; US Naval Reserve 1953-1968
White Hat, F6F Hellcat jock
----- Original Message -----
From: shad bell
To: pietenpol-list@matronics.com
Sent: Friday, November 11, 2011 3:09 PM
Subject: Re: Pietenpol-List: Vet's day
To ALL you ass kick'n freedom love'n Veterans, THANK YOU FOR ALL
YOU HAVE DONE, AND SACCRIFICED. Happy Veterans Day! And may God bless
you all, and your families.
Shad
Message 12
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Wing height above fuselage |
I did a search, but was unable to find any information on wing height above the
fuselage, limitations. I was able to sit in Tim's aircraft and thought that his
2" more than was the plans specify was OK, but what if i wanted to add an inch
or two more than that? Has anyone raised the wing 4"? Are there any adverse
effects?
Thanks
Joe
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=358040#358040
Message 13
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Wing height above fuselage |
Joe,
I'm not sure about there being any ill effects from raising it that much, b
ut in my humble opinion I think it would begin to look odd and somewhat un-
Pietenpolish.
Dan Helsper
Puryear, TN
-----Original Message-----
From: j_dunavin <j_dunavin@hotmail.com>
Sent: Tue, Nov 15, 2011 12:44 pm
Subject: Pietenpol-List: Wing height above fuselage
I did a search, but was unable to find any information on wing height above
the
uselage, limitations. I was able to sit in Tim's aircraft and thought that
his
" more than was the plans specify was OK, but what if i wanted to add an in
ch
r two more than that? Has anyone raised the wing 4"? Are there any adverse
ffects?
hanks
oe
ead this topic online here:
http://forums.matronics.com/viewtopic.php?p=358040#358040
-
-= -- Please Support Your Lists This Month --
-= (And Get Some AWESOME FREE Gifts!)
-
-= November is the Annual List Fund Raiser. Click on
-= the Contribution link below to find out more about
-= this year's Terrific Free Incentive Gifts provided
-= by:
-=
-= * AeroElectric www.aeroelectric.com
-= * The Builder's Bookstore www.buildersbooks.com
-= * HomebuiltHELP www.homebuilthelp.com
-
-= List Contribution Web Site:
-
-= --> http://www.matronics.com/contribution
-
-= Thank you for your generous support!
-
-= -Matt Dralle, List Admin.
-
-========================
-= - The Pietenpol-List Email Forum -
-= Use the Matronics List Features Navigator to browse
-= the many List utilities such as List Un/Subscription,
-= Archive Search & Download, 7-Day Browse, Chat, FAQ,
-= Photoshare, and much much more:
-
-= --> http://www.matronics.com/Navigator?Pietenpol-List
-
-========================
-= - MATRONICS WEB FORUMS -
-= Same great content also available via the Web Forums!
-
-= --> http://forums.matronics.com
-
-========================
-= - List Contribution Web Site -
-= Thank you for your generous support!
-= -Matt Dralle, List Admin.
-= --> http://www.matronics.com/contribution
-========================
Message 14
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Wing height above fuselage |
Hi Joe,
According to the notes from Bernard Pietenpol he raised the wing; i.e. lengthened
the cabane struts 4 inches on one of his last Corvair powered plances but thought
it looked a little too high but the airplane flew fine. Look in the supplemental
notes that come with the complete plan set from the Pietenpol family.
I raised mine three inches and it looks fine to me; but caveat is its not flying
yet.
Jim B.
Message 15
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Looks like the new Pietenpol project has made it into the Barnstormers cartoon
already.
BC
do not archive
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=358059#358059
Attachments:
http://forums.matronics.com//files/barntoons_15nov2011_797.jpg
Message 16
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Here are a couple of others from weeks past... even mentions Bryan by name. Ha
ha!
--------
Mark Chouinard
Wings, Center Section and Empannage framed up - Working on Fuselage
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=358063#358063
Attachments:
http://forums.matronics.com//files/194_barntoon_152.jpg
http://forums.matronics.com//files/191_barntoon_396.jpg
Message 17
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Chuck my dad served in the Navy also, he flew F4U-Corsairs, then P2V's in
the reserves. He is my hero and I hope he can some day fly the Piet with
me.
Jack
DSM
N1929T
_____
From: owner-pietenpol-list-server@matronics.com
[mailto:owner-pietenpol-list-server@matronics.com] On Behalf Of Chuck
Campbell
Sent: Tuesday, November 15, 2011 12:08 PM
Subject: Re: Pietenpol-List: Vet's day
US Navy, 1941-1945 ; 1951-1953; US Naval Reserve 1953-1968
White Hat, F6F Hellcat jock
----- Original Message -----
From: shad bell <mailto:aviatorbell@yahoo.com>
Sent: Friday, November 11, 2011 3:09 PM
Subject: Re: Pietenpol-List: Vet's day
To ALL you ass kick'n freedom love'n Veterans, THANK YOU FOR ALL YOU HAVE
DONE, AND SACCRIFICED. Happy Veterans Day! And may God bless you all, and
your families.
Shad
href="http://www.aeroelectric.com">www.aeroelectric.com
href="http://www.buildersbooks.com">www.buildersbooks.com
href="http://www.homebuilthelp.com">www.homebuilthelp.com
href="http://www.matronics.com/contribution">http://www.matronics.com/chref
"http://www.matronics.com/Navigator?Pietenpol-List">http://www.matronics.com
/Navigator?Pietenpol-List
href="http://forums.matronics.com">http://forums.matronics.com
href="http://www.matronics.com/contribution">http://www.matronics.com/c
Message 18
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Yes, my good friend Dennis Mclain the Barntoon cartoonist is having a lot of fun
with my building a Piet. : ) As a matter of fact most of his cartoons are poking
fun of somebody in our little local group.
I do not yet have the fuselage going but facts won't slow Dennis down. : ) I
have the tail feathers mostly done and would have been into the fuselage but Dennis
Hall invited me to Tucson last Sunday. He graciously let me try his Piet
on for size as well as opening up all of the inspection ports for me to see and
photograph all the inner workings. A very classy thing for him to do but for
those that know him, already knew he was that kind of guy. The hands on with
a finished one has clarified a lot of little details. It also made for some very
cool pictures when I stuffed my Nikon inside and snapped away.
See ya,
Bryan
--------
Workin Piet 5289B
While I may not always be right, I apologize well.
Read this topic online here:
http://forums.matronics.com/viewtopic.php?p=358078#358078
Message 19
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Wing height above fuselage |
2 cents -- Raising the wing farther above the thrust line should make it pitch
more with power changes. It would also act as if more dihedral was added.
Sent from my iPhone
On Nov 15, 2011, at 1:41 PM, "j_dunavin" <j_dunavin@hotmail.com> wrote:
>
> I did a search, but was unable to find any information on wing height above the
fuselage, limitations. I was able to sit in Tim's aircraft and thought that
his 2" more than was the plans specify was OK, but what if i wanted to add an
inch or two more than that? Has anyone raised the wing 4"? Are there any adverse
effects?
> Thanks
> Joe
>
>
>
>
> Read this topic online here:
>
> http://forums.matronics.com/viewtopic.php?p=358040#358040
>
>
>
>
>
>
>
>
>
>
Message 20
INDEX | Back to Main INDEX |
PREVIOUS | Skip to PREVIOUS Message |
NEXT | Skip to NEXT Message |
LIST | Reply to LIST Regarding this Message |
SENDER | Reply to SENDER Regarding this Message |
|
Subject: | Re: Wing height above fuselage |
Piet N Polish and un Pietenpolish, Dan, a new term to coin perhaps? Can you
provide an official definition to put into our dictionary.
And taking its rightful place somewhere between Buildapalooza and
Markeling, we now have Pietenpolish and Unpietenpolish!
Thanks Dan
John
Do Not Archive until the new dictionary is finished
Other Matronics Email List Services
These Email List Services are sponsored solely by Matronics and through the generous Contributions of its members.
-- Please support this service by making your Contribution today! --
|
