 Posted: Wed Feb 06, 2008 8:55 am Post subject: Sun-N-Fun BBQ 08 |
 |
|
Webmasters Sun-N-Fun BBQ 08
Last year was the largest event ever !
In the first week of registration I had over 80 people signed up, Sun-N-Fun 2007 was the Biggest Zenith event ever !! With over 200 people in attendence
Welcome to the 2008 BBQ sign up, Please take the time to visit www.ch601.org and www.ch701.com for the sign up sheet. This will be for your name tag and will be your ticket for the cooks to provide you with a great dinner. Plus this event is getting very large and I need an idea on how much food to buy so that we feed everyone and don't run out! Lets make it bigger this year, I have more give a ways, the first 50 people with a pre-registered name badge will receive a gift. Limit one per family please.
Thanks cdngoose
Don’t Miss Sun-N-Fun 2008 Thursday April 10th 2008
| | - The Matronics Zenith-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?Zenith-List |
|
| Description: |
|
| Filesize: |
70.64 KB |
| Viewed: |
417 Time(s) |
|
|
|
| Back to top |
|
 |
amyvega2005(at)earthlink.
Guest
|
| Posted: Thu Feb 07, 2008 5:53 pm Post subject: Sun-N-Fun BBQ 08 |
|
|
back to building planes...
I put the David Navone Noise Supressor circuit on My Becker radio and to my suprise, I still have radio noise. I have surmised it is ignition noise probably from the spark plugs or the cables. Has any one had noise in the radio due to ignition noise and did you get insulated cables? Any thoughts ladies?
Juan Vega , Jabiru 3300 601 xl
--
| | - The Matronics Zenith-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?Zenith-List |
|
|
|
| Back to top |
|
|
alaskajim(at)cox.net
Guest
|
| Posted: Thu Feb 07, 2008 7:04 pm Post subject: Sun-N-Fun BBQ 08 |
|
|
Am sorry to hear it didn't work for you. The noise filter totally
cured my noise problem. If I would have thought about it, I would
have had you try your radio with a separate motorcycle battery like I
did to affirm the noise was coming thru my power line. Your noise
must be coming from an "airborne" source. I didn't have any noise
when i used the MC battery so new it was coming thru the power
line. Jim
On Feb 7, 2008, at 6:50 PM, Juan Vega wrote:
[quote]
<amyvega2005(at)earthlink.net>
back to building planes...
I put the David Navone Noise Supressor circuit on My Becker radio
and to my suprise, I still have radio noise. I have surmised it is
ignition noise probably from the spark plugs or the cables. Has
any one had noise in the radio due to ignition noise and did you
get insulated cables? Any thoughts ladies?
Juan Vega , Jabiru 3300 601 xl
--
| | - The Matronics Zenith-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?Zenith-List |
|
|
|
| Back to top |
|
|
amyvega2005(at)earthlink.
Guest
|
| Posted: Fri Feb 08, 2008 3:58 pm Post subject: Sun-N-Fun BBQ 08 |
|
|
James,
no bog deal, at least the noise filter is on there now. What I need to find out is how to filter out th spark plug ignition noise. Any thoughts anyone?
Juan
--
| | - The Matronics Zenith-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?Zenith-List |
|
|
|
| Back to top |
|
|
bryanmmartin
Joined: 10 Jan 2006
Posts: 1018
|
| Posted: Fri Feb 08, 2008 6:16 pm Post subject: Sun-N-Fun BBQ 08 |
|
|
You can try using shielded wires on the magneto leads and grounding
the shields. These can be grounded at both ends, they are used to keep
noise on these wires from leaking out.
Use shielded wires for the audio circuits. Don't use the shield as
part of the circuit, use a separate wire for the audio lo line. I used
2 wire shielded cable for my audio output lines (audio hi and audio lo
inside a shield) and three wire shielded cable for my microphone lines
(audio hi, audio lo and PTT inside a shield). The shields on the audio
lines should be grounded on only one end. All of the audio shields
should be grounded at a common point, this is usually at the audio
panel or intercom panel since all of the audio lines go through there.
Use insulating washers to isolate your microphone and headset jacks
from ground. The shields on the audio lines are used to keep noise
getting into the audio wires. Grounding both ends of the audio shields
can create ground loops that can generate noise in the lines. Some
components ground the audio lo (common) lines and some don't. If you
are using the shield as the audio lo wire between two components that
have grounded audio lo lines, you end up with the shield grounded on
both ends, which may cause noise problems.
Make sure you have good solid connections on your RF coaxial cables.
Don't go cheap on the coax connectors, good quality crimp on
connectors crimped with the proper tool are worth the price. The
shields on the RF cables must be grounded on both ends as they form
part of the RF circuit. The comm antenna should be mounted well away
from the engine with a good ground plane.
On Feb 8, 2008, at 6:09 PM, Juan Vega wrote:
| Quote: |
>
James,
no bog deal, at least the noise filter is on there now. What I need
to find out is how to filter out th spark plug ignition noise. Any
thoughts anyone?
Juan
>
>
>
> Am sorry to hear it didn't work for you. The noise filter totally
> cured my noise problem. If I would have thought about it, I would
> have had you try your radio with a separate motorcycle battery like I
> did to affirm the noise was coming thru my power line. Your noise
> must be coming from an "airborne" source. I didn't have any noise
> when i used the MC battery so new it was coming thru the power
> line. Jim
>
>>
>> <amyvega2005(at)earthlink.net>
>>
>> back to building planes...
>> I put the David Navone Noise Supressor circuit on My Becker radio
>> and to my suprise, I still have radio noise. I have surmised it is
>> ignition noise probably from the spark plugs or the cables. Has
>> any one had noise in the radio due to ignition noise and did you
>> get insulated cables? Any thoughts ladies?
>>
>> Juan Vega , Jabiru 3300 601 xl
>>
>>
|
--
Bryan Martin
N61BM, CH 601 XL,
RAM Subaru, Stratus redrive.
do not archive.
| | - The Matronics Zenith-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?Zenith-List |
|
_________________
--
Bryan Martin
N61BM, CH 601 XL, Stratus Subaru.
do not archive. |
|
| Back to top |
|
|
zodierocket(at)hsfx.ca
Guest
|
| Posted: Tue Feb 12, 2008 4:10 am Post subject: Sun-N-Fun BBQ 08 |
|
|
4th Annual Webmasters BBQ
Last year was the largest event ever !
In the first week of registration I had over 80 people signed up, Sun-N-Fun 2007 was the Biggest Zenith event ever !! With over 200 people in attendence. So Far only 60 people have signed up, I need your help folks! The sign up is so that I can judge attendence and ensure that we have enough food for everyone, Please, Please take a few seconds to sign up. Surely we can make this Sun-N-Fun event even bigger. For those of you who have never attended please visit the link to view pictures and discover what it is all about.
Welcome to the 2008 BBQ sign up, Please take the time to visit www.ch601.org and www.ch701.com for the sign up sheet. This will be for your name tag and will be your ticket for the cooks to provide you with a great dinner. Plus this event is getting very large and I need an idea on how much food to buy so that we feed everyone and don't run out! Lets make it bigger this year, I have more give a ways, the first 50 people with a pre-registered name badge will receive a gift. Limit one per family please.
Thanks cdngoose
Don’t Miss Sun-N-Fun 2008 Thursday April 10th 2008
Last Years Sponsors were/ No Sponsors for this year yet.
Jabiru USA
William Wynne from www.flycorvair.com
[img]cid:image002.jpg(at)01C86D45.B005CBC0[/img][img]cid:image003.jpg(at)01C86D45.B005CBC0[/img] [img]cid:image004.jpg(at)01C86D45.B005CBC0[/img]
www.homebuilthelp.com
[img]cid:image005.jpg(at)01C86D45.B005CBC0[/img][img]cid:image006.jpg(at)01C86D45.B005CBC0[/img][img]cid:image007.jpg(at)01C86D45.B005CBC0[/img][img]cid:image008.jpg(at)01C86D45.B005CBC0[/img][img]cid:image009.jpg(at)01C86D45.B005CBC0[/img]
Quality Sport Planes
Mark Townsend Alma, Ontario
Zodiac 601XL C-GOXL, CH701 just started
www.ch601.org / www.ch701.com/ www.Osprey2.com
